Meter - Habotest HT206D Digital Clamp Meter True RMS, NCV, LPF
Product reference: 14-5907489606653

The Habotest HT206D is a digital clamp meter for measuring AC and DC voltage, current, resistance, capacitance and temperature. It features a backlit LCD display, non-contact voltage detection and a built-in flashlight for use in poorly lit areas.

Meter - Habotest HT206D Digital Clamp Meter True RMS, NCV, LPF

Product reference: 14-5907489606653

The Habotest HT206D is a digital clamp meter for measuring AC and DC voltage, current, resistance, capacitance and temperature. It features a backlit LCD display, non-contact voltage detection and a built-in flashlight for use in poorly lit areas.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
53,98 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
15 - 16
business days

Your message has been successfully sent!
Fill in the required fields*

Digital clamp multimeter Habotest HT206D True RMS, NCV, LPF


Habotest HT206D is a digital clamp multimeter for measuring AC and DC voltage, current, resistance, capacitance and temperature. It features a backlit LCD display, non-contact voltage detection and a built-in flashlight for use in low-light conditions.


  • Universal digital clamp multimeter for AC/DC voltage, current, resistance, capacitance and temperature measurements.
  • Non-contact voltage (NCV) detection for safe and easy voltage measurements.
  • Illuminated LCD display with two-color indicators for clear readings in low light conditions.
  • Built-in flashlight and intuitive controls for convenient use in any environment.

Features

Product type Digital clamp multimeter
Brand Habotest
Model HT206D

Specifications

DC voltage measurement range 600 mV/6 V/60 V/600 V ±(0.5%+5)
AC voltage measurement range 6V/60V/600V ±(0.8%+5)
DC current measurement range 60A/600A ±(2.5%+5)
AC current measurement range 60A/600A ±(2.5%+5)
Resistance measurement range 600 Ω/6 kΩ/60 kΩ/600 kΩ/6 MΩ/60 MΩ ±(1.0%+5)
Capacity measurement range 10 nF/100 nF/1 μF/10 μF/100 μF/1 mF/10 mF/100 mF ±(4.0%+3)
Frequency measurement range 10 Hz/100 Hz/1 kHz/10 kHz/100 kHz/1 MHz/10 MHz ±(1.0%+3)
Temperature measurement range -40°C to 1000°C ±(1.0%+2); -40°F to 1832°F ±(1.0%+2)
Number of digits 6000
Range selection Automatic
Continuity test Yes, sound and light signal
Diode testing Yes
Data storage Yes
Non-contact voltage detection (NCV) Yes, sound and light signal
Lighting Yes
Flashlight Yes
DCA zero Yes
Low battery indicator Yes
Automatic shutdown Yes
True RMS value Yes
LowZ Yes
Power supply 2x AAA 1.5V battery (included)
Weight About 260g
Dimensions 193x73x34 mm
Pliers size 26x44 mm
Security EN61010-1 -2-030; EN61010-2-033, EN61326-1 CAT III 600V

Height100mm
Length250mm
Weight390 g
Width150mm
