Zyxel XGS2220-54FP managed PoE switch
Managed Layer 3 switch with 48 Gigabit Ethernet ports, two 10G copper ports and four SFP+ ports. PoE support 50 ports, total power 960 W, VLAN, QoS, routing, authentication and multicast traffic control.
- Managed Level 3 PoE switch with 48 Gigabit Ethernet ports for business and enterprise networks
- Supports up to 50 PoE ports and has a total PoE power budget of 960W for access points, cameras, phones, and other devices
- Provides high-speed connectivity using 2 × 10G copper ports and 4 × installed SFP+ communication modules
- Advanced network management with VLAN, QoS, IGMP/MLD traffic tracking, authentication and routing support
Product identification | |
|---|---|
| Product type | Managed Layer 3 Gigabit Ethernet PoE Switch |
| Model | Zyxel XGS2220-54FP |
Ports and connectors | |
| RJ-45 Ethernet ports | 48 × Gigabit Ethernet (10/100/1000) |
| 10G copper ports | 2 |
| SFP+ modules installed | 4 |
| 10G support | Yes |
Network performance | |
| Switching speed | 216 Gbps |
| Transfer rate | 161 Mpps |
| MAC address table | 32,000 entries |
| Packet buffer memory | 2MB |
| Routing records | 64 |
| Large frame support | Yes |
Power over Ethernet | |
| PoE ports | 50 |
| PoE standards | IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt |
Management and protocols | |
| DHCP functions | DHCP Server and DHCP Relay |
| Authentication | IEEE 802.1X, RADIUS and TACACS+ |
| ARP inspection | Yes |
| IGMP functions | IGMP Proxy and IGMP Snooping |
| MLD flow tracking | MLD v1/v2 |
| VLAN registration | GVRP |
| Supported standards | IEEE 802.1D, 802.1p, 802.1Q, 802.1s, 802.1w, 802.1x, 802.3ab, 802.3ad, 802.3ae, 802.3an, 802.3az, 802.3x and 802.3z |
Power supply and installation | |
| Power source | Alternating current |
| Input voltage | 100-240V AC |
| Input frequency | 50-60Hz |
| Maximum power consumption | 1,161.6W |
| Power source | Attached |
| Mounting on a stand | Yes |
Physical properties | |
| Dimensions (W × H × D) | 441 × 44 × 330mm |
| Weight | 5 kg |
Environmental conditions | |
| Operating temperature | −20-50 °C |
| Operating humidity | 10-95% relative humidity |
| Storage temperature | −40-70 °C |
| Storage humidity | 10-90% relative humidity |
| Heat dissipation | 195.43 BTU/h |
Safety warning | |
| Warning | Intended for indoor installation of network equipment and use by professional IT professionals. Mount on a suitable stand or in a stable, well-ventilated location. Use only the supplied power supply and adhere to the specified voltage, temperature, and humidity ranges. Disconnect AC power before installation or maintenance, and do not exceed the specified PoE power budget. |
| Height | 580mm |
| Length | 500mm |
| Weight | 6285 grams |
| Width | 95 mm |
