LevelOne WAP-8231 wireless access point

LevelOne AX1800 Dual Band Wi-Fi 6 In-Wall PoE Wireless Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: WPA2-AES, WPA3. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White

The LevelOne new access point, the WAP-8231, can be used to create wireless networks that are not only technically perfect but also visually perfect. Since there is almost not to see with the wireless access point hardware: The wireless access point - just like a power outlet - is simply mounted on the wall. hotels and guesthouses can carefully set up WLANs for guests in each room. It can achieve a combined speed of up to 1800 Mbps. The WAP-8231 operates in the 2.4 and 5 GHz bands and can also be used as part of a managed network when controlled by the LevelOne WAC-2010 / WAC-2013 WLAN controller.

LevelOne WAP-8231 also offers PoE, removing the need for an external power supply, which makes it easy to install. A fast, versatile and secure access point for a wide variety of network requirements.

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 1800 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 1201 Mbit/s
Ethernet LAN data rates: 10,100,1000 Mbit/s
Frequency band: 2.412 -2.484, 5.18 - 5.825 GHz
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Cabling technology: 10/100/1000Base-T(X)
Channels quantity: 165 channels
Feature: MIMO
MIMO type: Multi User MIMO
Spread spectrum method: OFDMA
Operating modes: AP Mode

Security

Security algorithms: WPA2-AES, WPA3
Number of SSID supported: 8

Management features

Feature: Web-based management

Ports & interfaces

USB connector type: USB Type-C
WAN connection: Ethernet (RJ-45)

Power

Feature: Power over Ethernet (PoE)
Power consumption (typical): 14 W

Design

Placement: In-wall
Product colour: White
LED indicators: Wi-Fi

Antenna

Antenna type: Internal
Antennas quantity: 4
Antenna gain level (max): 3 dBi

Performance

Flash memory: 16 MB
Internal memory: 128 MB

Technical details

Master (outer) cases per pallet (air): 10 pc(s)
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Pallet height (air): 189 cm

Certificates

Compliance certificates: CE, RoHS, UKCA

Weight & dimensions

Width: 87 mm
Depth: 86 mm
Height: 31.5 mm
Weight: 138 g

Packaging data

Package width: 120 mm
Package depth: 110 mm
Package height: 65 mm
Package weight: 240 g
Package type: Box

Packaging content

Feature: Mounting kit
Interface adapter included: USB Type-C male - RJ-45 female
Feature: Quick start guide

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 10 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%

Sustainability

Feature: Sustainability compliance

Logistics data

Country of origin: China
Master (outer) case width: 515 mm
Master (outer) case length: 348 mm
Master (outer) case height: 580 mm
Master (outer) case gross weight: 25 kg
Products per master (outer) case: 100 pc(s)
