LevelOne POW-2442 power supply unit

LevelOne 24V DC Industrial Power Supply, 120W, DIN-Rail,-20 ~ +70 . Total power: 120 W, AC input voltage: 90 -264 V, AC input frequency: 47 - 63 Hz. Mean time between failures (MTBF): 2636800 h. Product colour: Blue, Silver. Safety: EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11.... Width: 40 mm, Depth: 113.5 mm, Height: 125.2 mm
The POW-2442 should be able to accept a wide range of input voltages, typically from 90V AC to 264V AC, allowing it to operate in various industrial environments.
DIN-rail Mounting to fit standard DIN-rail mounting systems commonly used in industrial cabinets, allowing for easy installation and space-saving.
It's essential for the power supply to have high energy efficiency, reducing power losses and operating costs while minimizing heat generation.

Power

Total power: 120 W
AC input voltage: 90 -264 V
AC input frequency: 47 - 63 Hz
Input current: 2.25 A
Hold time: 16 ms
Power protection features: Overload, Over voltage, Short circuit

Performance

Mean time between failures (MTBF): 2636800 h

Design

Product colour: Blue, Silver
Number of fans: 0 fan(s)

Operational conditions

Operating temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%

Weight dimensions

Width: 40 mm
Depth: 113.5 mm
Height: 125.2 mm
Weight: 530 g

Packaging data

Package width: 60 mm
Package depth: 140 mm
Package height: 143 mm
Package weight: 700 g
Package type: Box

Logistics data

Master (outer) cases per pallet: 20 pc(s)
Master (outer) case width: 310 mm
Master (outer) case length: 310 mm
Master (outer) case height: 305 mm
Master (outer) case gross weight: 14 kg
Harmonized System (HS) code: 8504403090
Country of origin: China

Other features

Voltage tolerance: 1%
Output voltage note: 24V
Maximum current: 5 A
