LevelOne POI-5003 PoE adapter

LevelOne Gigabit PoE Injector, 802.3 af/at/bt, 90W. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u. Product colour: Black. Total Power over Ethernet (PoE) budget: 90 W. Width: 65.3 mm, Depth: 40 mm, Height: 179.5 mm. Number of products included: 1 pc(s)

POI-5003 is a single port, high-power 90W PoE PSE solution for remote PoE PD devices. Generating up to 90W through 8 pins, POI-5003 supplies remote power for new applications such as wireless access points, pan-tilt-zoom (PTZ) IP cameras, lighting, panel display for digital signage and video-phones. It complies to IEEE 802.3bt PoE standards to deliver 90W on both end-point and midspan pairs with a total power of 90W PoE output. It can work with 10/100Base-T networking devices and emerging 1000Base-T devices such as Wi-MAX and wireless IEEE 802.11n access points.

Network

Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Power over Ethernet (PoE)
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u

Features

Product colour: Black
LED indicators: Yes

Ports & interfaces

RJ-45 input ports: 1
RJ-45 output ports: 1

Power

Total Power over Ethernet (PoE) budget: 90 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): 0 - 70 °C
Storage relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 65.3 mm
Depth: 40 mm
Height: 179.5 mm
Weight: 750 g

Packaging content

Number of products included: 1 pc(s)
Feature: Power cord included

Packaging data

Package width: 125 mm
Package depth: 55 mm
Package height: 210 mm
Package weight: 850 g
Package type: Box

Logistics data

Master (outer) cases per pallet (air): 12 pc(s)
Pallet gross length: 80 cm
Pallet gross width: 120 cm
Pallet height (air): 150 cm
Master (outer) case width: 220 mm
Master (outer) case length: 270 mm
Master (outer) case height: 290 mm
Master (outer) case gross weight: 9 kg
Products per master (outer) case: 10 pc(s)
Country of origin: China
