LevelOne NVR-0508 network video recorder

LevelOne GEMINI 8-Channel PoE Network Video Recorder, 8 PoE Outputs, H.265. Video input channels: 8 channels, Maximum resolution: 3840 x 2160 pixels, Video recording modes: 720p, 1080p. Maximum storage capacity: 12 TB, HDD interface: Serial ATA. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3at, Supported network protocols: TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP. LED indicators: Alarm, HDD, Power, Product colour: Black, Compatible products: Onvif camera. Power consumption (typical): 180 W, AC input voltage: 100 - 230 V

The LevelOne NVR-0508 NVR enables live view, recording and playback for up to 8 IP network cameras at the same time, featuring up to 8-megapixel resolution and H.265/H.264+/H.264/MPEG4 video compression. Operation is easy and intuitive via the web browser interface (IE), enabling remote monitoring and functionality. Mobile device operations are also supported (iOS/Android), with remote viewing via the LevelOne NVR app.

The NVR also features built-in HDMI, VGA and USB ports for peripheral devices such as a monitor, mouse or keyboard, allowing users to operate directly from the NVR without the cost of adding a PC to the deployment. 2 HDD bays complete the package, with a disk capacity of up to 6TB making the LevelOne NVR-0508 a powerful, smart and cost-effective solution for managing your security network.

An integrated 8-port 802.3at PoE switch enables the NVR to run both power and data on the one cable to power up connected PoE cameras.

Central Management System (CMS) software is included for free, with no license fees. The CMS is capable of managing up to 256 NVRs, making it suitable for large scale surveillance applications.

Performance

Video input channels: 8 channels
Video recording modes: 720p, 1080p
Maximum resolution: 3840 x 2160 pixels
Number of users: 64 user(s)
Video formats supported: H.264, H.264+, H.265, MPEG4
Operating system installed: Embedded LINUX
Throughput data rate: 160 Mbit/s
Number of fans: 1 fan(s)

Hard drive

HDD capacity: 0 GB
Number of HDDs supported: 2
Maximum storage capacity: 12 TB
HDD interface: Serial ATA

Ports & interfaces

Ethernet LAN (RJ-45) ports: 9
Feature: Power over Ethernet (PoE)
Ethernet LAN data rates: 10,100,1000 Mbit/s
Power over Ethernet (PoE) ports quantity: 8
Feature: HDMI output
VGA (D-Sub) output ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Audio RCA inputs: 1
Audio RCA outputs: 1
Networking standards: IEEE 802.3at
Supported network protocols: TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP

Features

Feature: Rack mounting
LED indicators: Alarm, HDD, Power
Feature: On/off switch
Product colour: Black
Compatible products: Onvif camera
Country of origin: China
Certification: CE, FCC, ISO9001, ISO14001, uL

Power

Power consumption (typical): 180 W
AC input voltage: 100 - 230 V

System requirements

Browser supported: Internet Explorer 9+

Operational conditions

Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 315 mm
Depth: 52 mm
Height: 385 mm
Weight: 3 kg
Package width: 435 mm
Package depth: 450 mm
Package height: 387 mm
Package type: Box
Package weight: 3.23 kg

Packaging content

Cables included: AC
Feature: AC adapter included
Feature: CD manual

Logistics data

Master (outer) case width: 548 mm
Master (outer) case length: 450 mm
Master (outer) case height: 412 mm
Master (outer) case gross weight: 14.1 kg
Products per master (outer) case: 4 pc(s)
