LevelOne FGU-5021 network switch

LevelOne 50-Port Fast Ethernet Switch, 2 x Gigabit SFP/RJ45 Combo. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 50, Console port: RJ-45. Full duplex. MAC address table: 8000 entries, Switching capacity: 13.6 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u. Rack mounting

- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX
- 9K jumbo frames to increase data transfer rates
- Supports 8K MAC address auto-learning and auto-aging
- 19-inch metal housing
- Quick and easy installation

Fast connections and fiber distances
FGU-5021 is a 48-port Fast Ethernet Switch (10/100 Mbps) that gives you a high-performance, low-cost, easy-to-use, solution to expand your network reach. With 2 Gigabit ports and 2 SFP Port , you're able to connect to other networks for flexible and powerful deployment options.

Plug and Play, Flexible and Easy
GSW-5150 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable. Diagnostic LEDs which display link status and activity, allowing you to quickly detect and correct problems on the network.

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 50
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity: 48
Gigabit Ethernet (copper) ports quantity: 2
Combo SFP ports quantity: 2
Fiber optic connector: SFP
Console port: RJ-45

Network

Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T, 1000BASE-TX
Feature: Full duplex
Feature: Auto MDI/MDI-X
Feature: Auto-negotiation
Feature: MAC address auto-learning supported
Feature: MAC address auto-aging supported

Optical fiber

Fiber ethernet cabling technology: 100BASE-X, 1000BASE-X

Data transmission

Switching capacity: 13.6 Gbit/s
MAC address table: 8000 entries
Feature: Store-and-forward
Feature: Jumbo frames support
Jumbo frames: 9000
Packet buffer memory: 4 MB

Design

Feature: Rack mounting
Product colour: Grey
Housing material: Metal
LED indicators: Activity, Link, Power

Performance

Internal memory: 16 MB

Power

Feature: Power supply included
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 28.6 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

Width: 44 mm
Depth: 230 mm
Height: 440 mm
Weight: 2.7 kg

Packaging content

Cables included: AC
Feature: Quick start guide

Packaging data

Package type: Gift box
Package width: 375 mm
Package depth: 100 mm
Package height: 510 mm
Package weight: 2.82 kg

Certificates

Certification: CE/FCC

Logistics data

Country of origin: China
Master (outer) case width: 520 mm
Master (outer) case length: 395 mm
Master (outer) case height: 535 mm
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 13.8 kg
Products per master (outer) case: 5 pc(s)
