LevelOne CVH-2000 network equipment chassis

LevelOne 14-Slot Media Converter Chassis. AC input voltage: 100-265 V, AC input frequency: 50 - 60 Hz. Certification: CE, FCC. Width: 427 mm, Depth: 315 mm, Height: 91 mm. Package dimensions (WxDxH): 550 x 410 x 185 mm, Package width: 550 mm, Package depth: 410 mm

14-Slot Media Converter Chassis
The LevelOne CVH-2000 media converter chassis is able to host up to 14 media converters. The chassis
supports LevelOne FVT-2001/2002/2201/2401 and GVT-2000/2001 Media Converts. All converters are
individually secured into the chassis and can be hot-swapped for maximum connection reliability.

The dual power supplies ensure continuous network operation. The Chassis is a standard 19-inch rack-
mountable size that easily fits into a server rack.

- Supports 14 slots for various type of Media Converters
- Converter module hot-swappable
- 10°C ~ 55°C operating temperature range

Technical details

Feature: Rack mounting
LED indicators: Power
Size (imperial): 48.3 cm (19")
Product colour: Black
Number of fans: 2 fan(s)
Number of bays: 14
Compliance certificates: RoHS
Country of origin: China
Compatible products: FVT-2001FVT-2002FVT-2201FVT-2401GVT-2000GVT-2001

Power

AC input voltage: 100-265 V
AC input frequency: 50 - 60 Hz

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 5 - 90%

Certificates

Certification: CE, FCC

Weight & dimensions

Width: 427 mm
Depth: 315 mm
Height: 91 mm
Weight: 420 g

Packaging data

Package dimensions (WxDxH): 550 x 410 x 185 mm
Package width: 550 mm
Package depth: 410 mm
Package height: 185 mm
Package weight: 860 g
