Switch - TP-Link TL-SG1016DE Black
Product reference: 14-1210002616751

TP-Link TL-SG1016DE - managed Layer 2 switch with 16 Gigabit Ethernet ports, VLAN, QoS and IGMP snooping support. The black, rack-mountable device provides 32 Gbit/s switching speed, but does not support PoE.

Switch - TP-Link TL-SG1016DE Black

Product reference: 14-1210002616751

TP-Link TL-SG1016DE - managed Layer 2 switch with 16 Gigabit Ethernet ports, VLAN, QoS and IGMP snooping support. The black, rack-mountable device provides 32 Gbit/s switching speed, but does not support PoE.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
125,46 €
126,73 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
8 - 9
business days

Your message has been successfully sent!
Fill in the required fields*

TP-Link TL-SG1016DE Black


TP-Link TL-SG1016DE - managed Layer 2 switch with 16 Gigabit Ethernet ports, VLAN, QoS and IGMP snooping support. The black, rack-mountable device provides 32 Gbit/s switching speed and does not support PoE.


  • Managed Layer 2 Gigabit Ethernet switch with 16 RJ-45 ports for reliable wired network connectivity.
  • Supports VLAN, QoS, link aggregation, port mirroring, and rate limiting, allowing flexible network management.
  • Provides 32 Gbit/s switching speed, 8,000-entry MAC address table, and up to 9,000-byte large frames.
  • Black, rack-mountable enclosure with IGMP snooping, broadcast storm control, and included power supply.

Product information

Product type Managed Layer 2 Gigabit Ethernet Switch
Brand TP-Link
Model TL-SG1016DE
Color Black

Ports and network

Ethernet ports 16 × RJ-45 Gigabit Ethernet (10/100/1000 Mbps)
Two-way communication mode Full duplex communication
Network standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and IEEE 802.3x
10G support No
Auto MDI/MDI-X Yes
IGMP snooping Yes

Management and performance

VLAN capacity Up to 32 VLANs
Switching method Recording and forwarding
MAC address table 8,000 entries
Packet buffer memory 0.5MB
Large frames Up to 9,000 bytes
Number of QoS queues 4

Additional features

Indicators LED indicators
Flow control Supported
Power over Ethernet Not supported
Installation Rack mountable; rack mounting kit included

Power supply and dimensions

Power input 100-240V AC, 50-60Hz
Maximum power consumption 11.73W
Dimensions 294 × 44 × 180 mm (width × height × depth)
Operating temperature 0-40°C
Operating humidity 10-90% relative humidity

Included accessories

Attached items Power supply, AC cable, rack mount kit, and user manual

Safety

Safety warning For use in indoor networks only. Connect and operate the switch with the supplied power cable within the specified electrical and environmental limits. Protect from moisture and ensure adequate ventilation during operation.

Height100mm
Length250mm
Weight1500g
Width350mm
