Imou Knight

Imou Knight. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired & Wireless. Mounting type: Ceiling/wall, Product colour: White, Housing material: Plastic. Lens viewing angle, horizontal: 107°, Lens viewing angle, vertical: 56°, Lens viewing angle, diagonal: 127°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Digital zoom: 16x, Fixed focal length: 2.8 mm

Performance

Type: IP security camera
Placement supported: Outdoor
Connectivity technology: Wired & Wireless
Feature: Built-in light
Luminous flux: 600 lm
Certification: CE, FCC

Design

Mounting type: Ceiling/wall
Product colour: White
Housing material: Plastic
Protection features: Dust resistant, Water resistant
International Protection (IP) code: IP66
Feature: Weatherproof

Camera

Lens viewing angle, horizontal: 107°
Lens viewing angle, vertical: 56°
Lens viewing angle, diagonal: 127°

Image sensor

Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Feature: Progressive scan
Sensor type: CMOS

Lens system

Feature: Zoom capability
Digital zoom: 16x
Fixed focal length: 2.8 mm

Night vision

Feature: Night vision
B/W night vision distance: 30 m
Colour night vision distance: 20 m

Video

Maximum resolution: 3840 x 2160 pixels
Total megapixels: 8 MP
Video compression formats: H.264, H.265
Frame rate: 15 fps

Audio

Feature: Built-in speaker(s)
Audio system: 2-way
Feature: Built-in microphone

Network

Feature: Ethernet LAN
Ethernet interface type: Fast Ethernet
Supported network protocols: ONVIF
Feature: Wi-Fi
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Frequency band: 2.5/5 GHz

Storage

Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 256 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1

Security

Feature: Built-in siren
Siren noise level: 110 dB
Feature: Video motion detection
Alert notification type: Text alert message
Feature: Configurable region
Feature: Configurable tripwire

Management features

Feature: Reset button

Power

Power source type: DC
Power consumption (typical): 9.2 W
DC output voltage: 12
DC output current: 1 A

Operational conditions

Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%

System requirements

Mobile operating systems supported: Android, iOS

Weight & dimensions

Width: 83.9 mm
Depth: 128.9 mm
Height: 71.2 mm
Weight: 580 g

Packaging content

Number of cameras: 1
Feature: Mounting kit
Feature: Mounting brackets included
Feature: Screws included
Feature: Manual
Feature: AC adapter included

Technical details

Legal guarantee: 3 year(s)
