HPE Networking Instant On Access Point Dual Radio 2x2 Wi-Fi 6 (RW) AP22D

HPE Networking Instant On Access Point Dual Radio 2x2 Wi-Fi 6 (RW) AP22D. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1200 Mbit/s. Security algorithms: OWE, WPA2, WPA3. Ethernet LAN data rates: 1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 51 W

The HPE Networking Instant On Access Points AP22D is an SMB-focused Wi-Fi CERTIFIED 6 access point that provides reliable wired and wireless connectivity over a 2.5 GbE uplink port with a minimal device footprint. This access point can reduce device clutter while powering downlink devices such as IP Phones or receipt printers with 2x 15W of PoE (802.3af) and supporting 75+ wireless devices over 802.11ax Wi-Fi 6 with an aggregate wireless throughput of 1.7 Gbps. Easily manage the Instant On AP22D with the Instant On mobile app or portal to create guest and employee networks, govern access control lists, and set PoE schedules to customize power use. Make the most of your limited space in your small business by mounting the Instant On AP22D to a desk or wall with included mounting kits.

What is new supporting point:
Wi-Fi CERTIFIED 6 wireless access point, with 2.5 GbE uplink port
2.5 GbE uplink port provides up to 2x more bandwidth than 1 GbE ports without the need for new Cat5/6(a) cables to be installed.
Four 1 GbE downlink ports that supply up to 2x 15W of PoE (802.3af).
Up to 1.7 Gbps aggregate wireless throughput.

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 1200 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Ethernet LAN data rates: 1000,2500 Mbit/s
Networking standards: IEEE 802.11ax
Cabling technology: 10/100/1000Base-T(X)
Number of users: 75 user(s)
Feature: MIMO
MIMO type: Multi User MIMO

Security

Security algorithms: OWE, WPA2, WPA3

Ports & interfaces

Ethernet LAN (RJ-45) ports: 5
USB 2.0 ports quantity: 1
Feature: DC-in jack

Power

Feature: Power over Ethernet (PoE)
DC voltage range: 48 V
Power consumption (typical): 50 W
Power consumption (max): 51 W

Design

Placement: Desk, Wall
Product colour: White
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: Reset button

Antenna

Antenna type: Internal
Antenna direction type: Semi-directional
Antennas quantity: 2
Antenna gain level (max): 5.4 dBi

Certificates

Certification: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Weight & dimensions

Width: 86 mm
Depth: 47 mm
Height: 150 mm
Weight: 360 g

Other features

Mounting: Gang wall box-mount kit or Desk-mount kit

Operational conditions

Operating temperature (T-T): 0 - 40 °C
