HPE BladeSystem c-Class 10Gb SFP+ SR Transceiver network transceiver module

HPE BladeSystem c-Class 10Gb SFP+ SR Transceiver. Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+, Fiber optic connector: LC. Compatible products: HP BladeSystem c-Class. Power consumption (typical): 0.8 W. Certification: MSA. Width: 55.7 mm, Depth: 13.8 mm, Height: 11.9 mm

.

Performance

Maximum data transfer rate: 10000 Mbit/s
Interface type: SFP+
Feature: Multi-mode fiber (MMF) supported
Fiber optic connector: LC
Fiber cable diameters supported (core/cladding): 62.5/125, 50/125 µm
Maximum transfer distance: 300 m
Wavelength: 850 nm
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u
Cabling technology: 10GBASE-SR
Feature: Auto MDI/MDI-X

Features

Feature: Hot-Plug support
Feature: Hot-swap
Compatible products: HP BladeSystem c-Class

Power

Power consumption (typical): 0.8 W

Certificates

Certification: MSA

Operational conditions

Operating temperature (T-T): 0 - 70 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 10 - 80%
Storage relative humidity (H-H): 10 - 85%

Weight & dimensions

Width: 55.7 mm
Depth: 13.8 mm
Height: 11.9 mm
Weight: 20 g

Logistics data

Harmonized System (HS) code: 85369010
