HPE Aruba Networking Networking Instant On Indoor Access Point Wi-Fi 6 4x4 (RW) AP25

HPE Aruba Networking Networking Instant On Indoor Access Point Wi-Fi 6 4x4 (RW) AP25. 2.4 GHz, 5 GHz, Maximum data transfer rate: 4800 Mbit/s. Security algorithms: OWE, WPA2, WPA3. Ethernet LAN data rates: 2500 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 20.1 W

Wi-Fi Certified 6TM HPE Networking Instant On Access Points AP25 delivers faster Wi-Fi speeds, greater capacity, and reduced latency between access points and devices for a superior Wi-Fi experience. With the AP25, you can upgrade your Wi-Fi network to boost performance across devices now, while preparing it for more mobile and IoT devices in the future. Features include Orthogonal frequency-division multiple access (OFDMA), multi-user MIMO, and target wake time (TWT). With up to 4 spatial streams (4SS) and 160 MHz channel bandwidth (HE160), the Instant On AP25 provides outstanding wireless capabilities for businesses looking to future-proof their networks.

What is new supporting point:
This series features maximum data rates of 4.8 Gbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band (for an aggregate peak data rate of 5.3 Gbps)
Includes 2.5 Gigabit Ethernet uplink port and 160 MHz channel bandwidth for increased wireless throughput
Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access
Instant On mobile app and/or cloud-based web portal allows for easy network management onsite or remotely
Wi-Fi 6 certification supports all mandatory 802.11ax features that include MU-MIMO, OFDMA, TWT, and more
Provides a high performance Dual Radio 802.11ax AP with 4 spatial streams (4X4) for higher capacity and coverage

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 4800 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 4800 Mbit/s
Ethernet LAN data rates: 2500 Mbit/s
Networking standards: IEEE 802.11ax
Number of users: 100 user(s)
Feature: Bluetooth Low Energy (BLE)
Feature: MIMO
MIMO type: Multi User MIMO

Security

Security algorithms: OWE, WPA2, WPA3

Management features

Feature: Web-based management

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 1
Feature: DC-in jack

Power

Feature: Power over Ethernet (PoE)
DC voltage range: 12 V
Power consumption (max): 20.1 W

Design

Placement: Ceiling, Wall
Product colour: White
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: Reset button

Antenna

Antenna type: Internal
Antenna direction type: Omni-directional
Antenna gain level (max): 4.5 dBi

Certificates

Certification: Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Weight & dimensions

Width: 203 mm
Depth: 45 mm
Height: 51 mm
Weight: 1.18 kg

Other features

I/O ports: 1x 2.5 GbE Base-T uplink port DC power connector Bluetooth Low Energy (BLE) LED status indicators Reset/LED control button Kensington security slot
Mounting: Ceiling/Wall mount clip
Weight (imperial): 1.18 kg (2.6 lbs)

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Logistics data

Harmonized System (HS) code: 85176990
