HPE Aruba Networking AP-605R12-EU Wi-Fi 6E CAT12 LTE Dual-radio Tri-band 2x2 Remote AP

HPE Aruba Networking AP-605R12-EU Wi-Fi 6E CAT12 LTE Dual-radio Tri-band 2x2 Remote AP. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 3600 Mbit/s. Security algorithms: WPA3. Ethernet LAN data rates: 1000,2500,5000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 40 W
HPE Aruba Networking 600R Series Remote Access Points are powerful desktop Wi-Fi 6E access points that enable IT teams to deliver seamless and secure user experiences to remote power users and small branch environments. Providing up to 3.6 Gbps combined aggregate data rate (using 5 GHz and 6 GHz bands), this series delivers more wireless capacity and wider channels by taking advantage of Wi-Fi 6E and the 6 GHz band to more than double capacity to support increasing Wi‐Fi demands, especially for latency‐sensitive, high‐bandwidth video communications. An optional high-speed LTE cellular module provides primary or backup connectivity for mission critical use cases. Multigigabit port, gigabit ports, and integrated Bluetooth Low Energy (BLE) and Zigbee offer a range of connectivity options. IT teams can easily extend the WAN to remote employees as part of the HPE Aruba Networking Central microbranch functionality. The 600R series includes a limited lifetime warranty.
What is new supporting point:
Wi-Fi 6E access points ideal for mission-critical remote work and small branches provide flexible coverage across any two bands (2.4 GHz, 5 GHz, and 6 GHz) for up to 3.6 Gbps combined peak data rate
Stay connected using backup or primary cellular connectivity with optional CAT 12 module that includes antennas and a high-speed interface for LTE connectivity
Convenient wired connectivity with 2.5 Gbps uplink/downlink Ethernet port and multiple 1 Gbps Ethernet ports
Zero touch provisioning (ZTP) provides ease of implementation in branch offices and remote sites, without on-site technical expertise
Managed through cloud-native HPE Aruba Networking Central to extend the WAN to home offices, small offices, and temporary locations

Features

Feature: 2.4 GHz
Feature: 5 GHz
Feature: 6 GHz
Maximum data transfer rate: 3600 Mbit/s
Maximum data transfer rate (2.4 GHz): 287 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Maximum data transfer rate (6 GHz): 2400 Mbit/s
Ethernet LAN data rates: 1000,2500,5000 Mbit/s
Frequency band: 20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.6 Gbps
Networking standards: IEEE 802.11ax, IEEE 802.11mc
Feature: Bluetooth
Bluetooth version: 5.0
Feature: Bluetooth Low Energy (BLE)
Feature: MIMO
MIMO type: Single User MIMO
Spread spectrum method: DSSS, OFDM, OFDMA
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: Maximal-Ratio Combining (MRC)
Feature: Cyclic Delay Diversity (CDD)
Feature: Cyclic Shift Diversity (CSD)
Feature: Dynamic Frequency Selection (DFS)
Feature: Trusted Platform Module (TPM)

Security

Security algorithms: WPA3

Management features

Access point management: On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service

Ports interfaces

Ethernet LAN (RJ-45) ports: 5
USB 2.0 ports quantity: 1

Power

Feature: Power over Ethernet (PoE)
DC voltage range: 48 V
Power consumption (typical): 5 W
Power consumption (max): 40 W

Design

Placement: Table
Product colour: White
Feature: Cable lock slot
Cable lock slot type: Kensington
Recommended usage: Indoor

Antenna

Antenna type: External
Antenna direction type: Omni-directional
Antenna features: Integrated antenna
Antennas quantity: 2
Antenna gain level (max): 5.5 dBi

Performance

Compatible operating systems: HPE Aruba Networking Wireless Operating System OS-10

Certificates

Compliance certificates: Federal Communications Commission (FCC), ISED, CE, Low Voltage Directive (LVD)

Weight dimensions

Width: 225 mm
Depth: 150 mm
Height: 40 mm
Weight: 900 g

Packaging data

Package width: 373 mm
Package depth: 309 mm
Package height: 107 mm
Package weight: 1.94 kg

Operational conditions

Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -25 - 55 °C
Storage relative humidity (H-H): 10 - 100%
