Hikvision Pro Series with ColorVu DS-2CD2T47G2H-LI(2.8mm)(eF)

Hikvision Pro Series with ColorVu DS-2CD2T47G2H-LI(2.8mm)(eF). Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 104°, Lens viewing angle, vertical: 54.4°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 61 m, Observe distance: 24 m, Recognize distance: 12 m
4 MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera
Security requirements and application settings vary. That's why Hikvision designs and tailors network cameras to meet various needs, from general video monitoring to video content analytics with deep learning algorithms and beyond.
By rendering high-quality images across a range of lighting conditions, minimizing storage and bandwidth requirements and providing data-powered situational awareness, Hikvision network cameras can help users make smart decisions. Our network cameras are the ideal choice for hundreds of application scenarios.

Performance

Type: IP security camera
Placement supported: Outdoor
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Built-in light: Yes
Number of languages: 33
Languages support: Multi
Dynamic range: 130 dB

Design

Form factor: Bullet
Mounting type: Wall
Product colour: White
Housing material: Metal
Protection features: Dust resistant, Water resistant
International Protection (IP) code: IP67

Camera

Minimum illumination: 0 lx
Angle of rotation: 360°
Lens viewing angle, horizontal: 104°
Lens viewing angle, vertical: 54.4°
Lens viewing angle, diagonal: 126.7°
Tilt angle range: 0 - 90°
Pan range: 0 - 360°
Camera shutter speed: 1/3 - 1/100000 s
Number of Privacy masking areas: 4

Image sensor

Number of sensors: 1
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Progressive scan: Yes
Sensor type: CMOS

Lens system

Number of lenses: 1
Detect distance: 61 m
Observe distance: 24 m
Recognize distance: 12 m
Fixed focus: Yes
Maximum aperture number: 1
Identify distance: 6 m
Fixed focal length: 2.8 mm

Night vision

Night vision: Yes
Night vision distance: 60 m
LED type: IR
Infra-red wavelength: 850 nm

Video

Maximum resolution: 2688 x 1520 pixels
Total megapixels: 4 MP
Video compression formats: H.264, H.264+, H.265, H.265+, M-JPEG
Supported graphics resolutions: 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520
Frame rate: 30 fps
Video streaming: Yes
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Image quality adjustment: Brightness, Contrast, Saturation, Sharpness
Privacy masking: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate: 32 Kbps - 8 Mbps
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Region of Interest (ROI) encoding: Yes

Network

Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Supported network protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Wi-Fi: No
Bluetooth: No
Number of users: 32 user(s)
User access level: Administrator, Operator, User
Quality of Service (QoS) support: Yes
Client interoperability: iVMS-4200, Hik-Connect, Hik-Central
Live view: Yes
Number of simultaneous live view channels: 6 channels

Storage

Built-in HDD: No
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size: 512 GB

Ports interfaces

Ethernet LAN (RJ-45) ports: 1

Security

Password protection: Yes
Video motion detection: Yes
Active tampering alarm: Yes
IP address filtering: Yes
Security algorithms: EAP-LEAP, EAP-MD5, EAP-TLS
HTTPS encryption: Yes
Privacy protection: Yes
Heartbeat: Yes
Mirror: Yes
Digital watermark: Yes
Password reset via email: Yes
Pixel counter: Yes
Human and vehicle targets classification: Yes
Audit log: Yes
Automatic Network Replenishment (ANR): Yes
Digest authentication: Yes
Network access storage (NAS): Yes

Management features

Web-based management: Yes
Reset button: Yes
Behavior analysis: Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection

Power

Power source type: DC, PoE
Power consumption (max): 8 W
Power consumption (Power over Ethernet (PoE)): 9 W
DC output voltage: 12
DC output current: 0.66 A

Operational conditions

Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%

Weight dimensions

Width: 93.3 mm
Height: 91.2 mm
Length: 286.7 mm
Weight: 1.08 kg

Packaging data

Package width: 386 mm
Package depth: 156 mm
Package height: 155 mm
Package weight: 1.64 kg

Sustainability

Sustainability compliance: Yes
Compliance certificates: BIS, CB, CE, Industry Canada (IC), KC, Low Voltage Directive (LVD), RCM, RoHS, UL

Packaging content

Number of cameras: 1

Technical details

Iris: Yes
Lens mount interface: M16
