HDMI Extender - DIGITUS 4K / 60 Hz Cat6 IP PoE Kit
Product reference:
14-4016032501916
The HDMI transmitter and receiver set transmits 4K image at 60 Hz over Cat6 cable up to 200 m away. Supports HDMI 2.0, 18 Gbit/s bandwidth, HDCP 1.4/2.2, IR control and PoE.
HDMI Extender - DIGITUS 4K / 60 Hz Cat6 IP PoE Kit
Product reference:
14-4016032501916
The HDMI transmitter and receiver set transmits 4K image at 60 Hz over Cat6 cable up to 200 m away. Supports HDMI 2.0, 18 Gbit/s bandwidth, HDCP 1.4/2.2, IR control and PoE.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
DIGITUS HDMI extender 4K/60 Hz Cat6 IP PoE kit
The HDMI transmitter and receiver set transmits 4K images at 60 Hz up to 200 m over Cat6 cable. Supports HDMI 2.0, 18 Gbit/s bandwidth, HDCP 1.4/2.2, IR control and PoE.
- HDMI 2.0 signals are transmitted over a Cat6 network cable at distances of up to 200 m
- Supports 4K Ultra HD resolution up to 4096 × 2160, 60 Hz frequency and 18 Gbit/s bandwidth
- PoE support simplifies installation as power is supplied via the network connection
- IR input and output for convenient remote control signal transmission
Product information | |
|---|---|
| Product type | HDMI Transmitter and Receiver Kit |
| Brand | DIGITUS |
| Connection | Wired connection via Cat6 network cable |
| Color | Black |
| Material | Metal |
Technical data | |
| HDMI version | 2.0 |
| HDCP support | HDCP 1.4 and 2.2 |
| Supported video mode | 2160p |
| Operating temperature | from -20°C to 60°C |
| Protection against electrostatic discharge | Yes |
| LED indicators | Yes |
| Can be mounted on the wall | Yes |
Power supply | |
| Power over Ethernet | Yes |
| Power source | 5 V DC |
| Maximum power consumption | 2.5 W per transmitter or receiver |
| Output current | 1 A |
| External power adapter | Yes |
Ports and interfaces | |
| HDMI input | 1 |
| HDMI output | 1 |
| RJ-45 input | 1 |
| RJ-45 output | 1 |
| IR input | 1 |
| IR output | 1 |
| 3.5mm audio input | Yes |
| 3.5mm audio output | Yes |
| USB ports | 2 |
| USB connection | Micro USB |
| DC input | Yes |
Dimensions and package contents | |
| Transmitter dimensions | 94 × 97 × 24 mm (width × depth × height) |
| Receiver dimensions | 94 × 97 × 24 mm (width × depth × height) |
| Transmitter weight | 166 g |
| Receiver weight | 164 g |
| Included accessories | IR cables, AC adapter and quick start guide |
Safety information | |
| Safety warning | Use the extender only to transmit HDMI signals using a Cat6 compatible cable. Install and use in a dry, well-ventilated area, use the included or compatible power supply, and unplug the device from the power source before cleaning or performing maintenance. |
| Height | 100mm |
| Length | 210 mm |
| Weight | 570g |
| Width | 160mm |
