GS-2426P

GS-2426P. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries. Networking standards: IEEE 802.3af, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az, IEEE 802.1x. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Managed Gigabit access switch with PoE+
The LANCOM GS-2426P is an efficient LAN-side foundation for small and medium-sized enterprises (SME) that require a reliable Layer 2 switching solution with Power over Ethernet. Its Layer 2 functionality, including VLAN support, QoS, and advanced security mechanisms, optimizes data traffic and protects the network from unauthorized access. With 24 PoE+-capable Gigabit Ethernet ports (IEEE 802.3af/at) and a total PoE output of 185 watts, the access switch supplies connected end devices - such as IP cameras and access points - with power, eliminating the need for additional power supply units or complex cabling. Two additional combo ports (TP/SFP) enable flexible network expansion via fiber-optic or copper connections. For easy management, a web-based GUI, a CLI, and the LANCOM Management Cloud (LMC) are available - ideal for centralized device configurations and automated rollouts.

Management features

Switch type: Managed
Switch layer: L2
Feature: Quality of Service (QoS) support
Feature: Web-based management
Feature: Cloud-managed
Feature: Configuring Location Settings (CLI)
MIB support: Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 2
Power connector: AC-in jack

Network

Networking standards: IEEE 802.3af, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az, IEEE 802.1x
Feature: Port mirroring
Feature: Flow control support
Feature: Broadcast storm control
Feature: Spanning tree protocol
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: VLAN support
Number of VLANs: 4096

Data transmission

Throughput: 52 Gbit/s
MAC address table: 8000 entries
Feature: Jumbo frames support
Jumbo frames: 9000
Packet forwarding rate (1 Gbps): 38.69 pps

Security

DHCP features: DHCP client, DHCP relay
Feature: Access Control List (ACL)
Feature: IGMP snooping
Security algorithms: SNMP, SNMPv2, SNMPv3
Feature: SSH/SSL support
Feature: Loop protection
Feature: Password protection

Multicast features

Feature: Multicast support

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Black
LED indicators: Yes

Power

Power source: AC
Feature: Power supply included
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 240 W

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 24
Total Power over Ethernet (PoE) budget: 185 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 442 mm
Depth: 212 mm
Height: 44 mm
Weight: 2.5 kg

Packaging content

Feature: Manual

Logistics data

Customs product code (TARIC): 85176200
Country of origin: Taiwan
