GS-2412P

GS-2412P. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 8000 entries. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting

Compact, silent, efficient: Gigabit access switch with PoE+
Whether in quiet business premises, professional small offices, or growing branch networks, the LANCOM GS-2412P provides a powerful and silent solution for efficient network management. This fanless Gigabit access switch connects up to twelve end devices via ten Gigabit Ethernet ports and two additional SFP ports. With Power over Ethernet (PoE+) and a total output of 130 watts, up to eight PoE-powered devices can be reliably supplied with power via IEEE 802.3af/at, eliminating the need for additional power supply units or cabling. For Layer 2+ switch management, users can choose between a web-based GUI, a CLI, or the LANCOM Management Cloud (LMC) for centralized, automated device rollouts and configurations.

Management features

Switch type: Managed
Switch layer: L2+
Feature: Quality of Service (QoS) support
Feature: Web-based management
Feature: Cloud-managed
Feature: Configuring Location Settings (CLI)
MIB support: Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 10
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Power connector: AC-in jack

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w
Feature: Port mirroring
Feature: Policy-based routing
Feature: Flow control support
Feature: Broadcast storm control
Feature: Spanning tree protocol
Ethernet LAN data rates: 10,1000,100 Mbit/s
Feature: VLAN support
Number of VLANs: 4096

Data transmission

Throughput: 24 Gbit/s
MAC address table: 8000 entries
Feature: Jumbo frames support
Jumbo frames: 9000
Packet forwarding rate (1 Gbps): 14.88 pps

Security

DHCP features: DHCP relay, DHCP client
Feature: Access Control List (ACL)
Feature: IGMP snooping
Security algorithms: SNMP, SNMPv2, SNMPv3
Feature: SSH/SSL support
Feature: Loop protection
Feature: Password protection

Multicast features

Feature: Multicast support

Design

Feature: Rack mounting
Product colour: Black
LED indicators: Yes

Power

Power source: AC
Feature: Power supply included
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 160 W

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 8
Total Power over Ethernet (PoE) budget: 130 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 220 mm
Depth: 242 mm
Height: 45 mm
Weight: 2.35 kg

Packaging content

Feature: Manual

Logistics data

Customs product code (TARIC): 85176200
Country of origin: Taiwan
