Grandstream Networks GWN7604 wireless access point

Grandstream Networks GWN7604. 2.4 GHz, 5 GHz, Maximum data transfer rate: 867 Mbit/s. Security algorithms: WEP, WPA, WPA2, WPA2-PSK. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 6.5 W

Wi-Fi 6 Access Point with Integrated PoE Switch
The GWN7604 is a compact and versatile Wi-Fi 6 Access Point with 4 Gigabit Ethernet ports, including one uplink port that can receive PoE/PoE+ to power the access point and two ports with PSE that can provide PoE and a network connection to other devices.

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 867 Mbit/s
Maximum data transfer rate (2.4 GHz): 300 Mbit/s
Maximum data transfer rate (5 GHz): 867 Mbit/s
Ethernet LAN data rates: 10,100,1000 Mbit/s
Number of users: 100 user(s)
Feature: MIMO
MIMO type: Multi User MIMO
Maximum indoor range: 100 m

Security

Security algorithms: WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported: 16

Ports & interfaces

Ethernet LAN (RJ-45) ports: 4

Power

Feature: Power over Ethernet (PoE)
Power consumption (max): 6.5 W

Design

Placement: Wall
Product colour: White
Cable lock slot type: Kensington

Antenna

Antenna type: Internal
Antennas quantity: 2

Certificates

Compliance certificates: CE
Certification: FCC, CE, RCM, IC

Weight & dimensions

Width: 135 mm
Depth: 115 mm
Height: 30 mm
Weight: 253 g

Packaging data

Package width: 171 mm
Package depth: 140 mm
Package height: 33 mm
Package weight: 358 g
Package type: Box

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): 10 - 60 °C
