Dragino Technology DLOS8N-868-EC25-E gateway / controller

Dragino Technology DLOS8N-868-EC25-E. Product colour: White. Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af. Input voltage: 12 - 24 V, Input current: 2 A. Weight: 1.7 kg. Package width: 490 mm, Package depth: 120 mm, Package height: 190 mm

The DLOS8N is an open source outdoor LoRaWAN Gateway. It lets you bridge LoRa wireless network to an IP network via WiFi, Ethernet, 3G or 4G cellular. The LoRa wireless allows users to send data and reach extremely long ranges at low data-rates.

DLOS8N supports Semtech packet forwarder and LoRaWAN Station connection, it is fully compatible with LoRaWAN protocol. DLOS8N includes a SX1302 LoRaWAN concentrator.

DLOS8N has pre-configured standard LoRaWAN frequency bands to use for different countries.User can also customize the frequency bands to use in their own LoRaWAN network.

DLOS8N can communicate with ABP LoRaWAN end node without LoRaWAN server. System integrator can use it to integrate with their existing IoT Service without set up own LoRaWAN server or use 3rd party LoRaWAN service.

DLOS8N supports auto-provision for mass deployment and long term maintain. System intergrator can easily change the settings.

Design

Product colour: White

Network

Ethernet LAN data rates: 10,100 Mbit/s
Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Feature: Wi-Fi

Ports & interfaces

USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1

Power

Input voltage: 12 - 24 V
Input current: 2 A
Feature: Power over Ethernet (PoE)

Weight & dimensions

Weight: 1.7 kg

Packaging data

Package width: 490 mm
Package depth: 120 mm
Package height: 190 mm
Package weight: 2.5 kg

Operational conditions

Operating temperature (T-T): -20 - 85 °C
