Digitus DN-95116 network switch

Digitus 16-port 10G Ethernet PoE+ injector, 802.3at, 250 W. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex, Networking standards: IEEE 802.3af. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Minimization of cabling effort for PoE-capable devices

- 16 10G ports with PoE+ support
- 250 watts of power with up to 30 watts per port
- Compatible with the IEEE802.3at standards
- Automatic overvoltage protection
- Supports bandwidths up to 10Gbps

The DIGITUS® DN-95116 is a 16 port 10G PoE+ mid-span hub (PoE injector). It offers 16 input ports for data and 16 output ports that provide data and PoE. Each PoE port supports connected devices according to the PoE standard IEEE802.3af and IEEE802.3at with 15.4 watts and 30 watts respectively, such as PoE access points, PoE IP telephones or PoE IP cameras. The switch provides a maximum budget of 250 watts for all ports and a maximum budget of 30 watts per port.

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: AC-in jack

Network

Networking standards: IEEE 802.3af
Feature: Full duplex
Feature: Auto MDI/MDI-X

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Grey
LED indicators: Power
Feature: On/off switch

Performance

Feature: Plug and Play
Mean time between failures (MTBF): 100000 h

Power

AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 3 A
Power consumption (max): 250 W
Feature: Surge protection
Power protection features: Overload, Short circuit

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 16
Power over Ethernet (PoE) voltage range: 1.2 - 3.6 V
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 250 W

Other features

Ethernet interface type: Gigabit Ethernet

Operational conditions

Operating temperature (T-T): -10 - 45 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 200 mm
Depth: 440 mm
Height: 45 mm
Weight: 2.8 kg

Packaging content

Cables included: AC
Feature: Quick start guide

Packaging data

Package type: Box
Package width: 280 mm
Package depth: 500 mm
Package height: 100 mm
Package volume: 14000 cm³
Package weight: 4.17 kg

Logistics data

UK Trade Tariff code: 85176200
Country of origin: China
Harmonized System (HS) code: 85176990
