Digitus DN-95103-3 PoE adapter

Digitus Gigabit Ethernet PoE+ injector, 802.3at, 30 W. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000. Product colour: Black, Maximum operating distance: 800 m. AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50/60 Hz, Input current: 0.6 A. Width: 142 mm, Depth: 60 mm, Height: 32 mm. Number of products included: 1 pc(s)

With the PoE Injector, you benefit from a powerful and reliable network extension - wherever power sources are lacking.

- Compatibility: Supports IEEE802.3af/at standards, ideal for all compatible PoE devices
- High performance: Delivers up to 30W of power and supports gigabit data transmission
- Simple installation: plug-and-play operation without configuration effort
- Range: power and data transmission up to 100 m possible
- Intelligent protection mechanisms: short-circuit protection and overload protection ensure a safe power supply
- Robust design: Durable plastic housing that combines elegance with functionality
- Energy efficiency: Automatic detection of connected devices for optimum power supply

The PoE injector is the ideal solution for expanding your network in locations without a power connection. Fully compatible with the IEEE 802.3af/at standards, it is perfect for power supply and data transmission for PoE-capable devices such as access points (AP), IP cameras, IP telephones or PoE receivers. Thanks to its powerful features, the PoE injector ensures a stable and reliable connection without the need for additional configurations. An elegant design and robust protection mechanisms make it the first choice for demanding applications.

Network

Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000
Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: PoE+
Networking standards: IEEE 802.3at
Cable types supported: Cat3, Cat5, Cat5e, Cat6

Features

Product colour: Black
Maximum operating distance: 800 m
LED indicators: Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2
RJ-45 input ports: 1
RJ-45 output ports: 1
Feature: DC-in jack

Power

AC adapter input voltage: 100 - 240 V
AC adapter frequency: 50/60 Hz
Input current: 0.6 A
Total Power over Ethernet (PoE) budget: 30 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C

Weight & dimensions

Width: 142 mm
Depth: 60 mm
Height: 32 mm

Packaging content

Number of products included: 1 pc(s)
Feature: Quick installation guide

Packaging data

Package width: 165 mm
Package depth: 192 mm
Package height: 60 mm
Package weight: 490 g
Package type: Box

Logistics data

Country of origin: China
