Digitus DN-95102-1 PoE adapter

Digitus Gigabit Ethernet PoE Injector, 802.3af, 15,4 W. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3af. Power over Ethernet (PoE) voltage: 48 V, Output power: 15.4 W, AC adapter input voltage: 100 - 240 V. Dimensions (WxDxH): 56 x 134 x 33 mm. Package width: 140 mm, Package depth: 160 mm, Package height: 50 mm. Master (outer) case width: 315 mm, Master (outer) case length: 475 mm, Master (outer) case height: 340 mm

Minimize cabling for wireless APs, IP phones, or any other PoE compatible device!

- Meets the 802.3af PoE standard
- 48V output voltage, 15.4 Watt
- Cable connection: 10/100/1000 Mbps
- Power consumption: 1.6W max.

The Digitus PoE Injector minimizes your cabling when installing PoE compatible devices such as IP network cameras. Only the Ethernet cable is used for the data feed and power supply for the devices. This eliminates the need to install a separate power line, and you can extend your network where there are no power outlets or power lines. The injector is fully compliant with the IEEE 802.3af PoE standard and delivers output power of up to 15.4W.

Network

Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Power over Ethernet (PoE)
Networking standards: IEEE 802.3af

Features

LED indicators: Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
Feature: DC-in jack

Power

Power over Ethernet (PoE) voltage: 48 V
Output power: 15.4 W
AC adapter input voltage: 100 - 240 V
Input current: 0.8 A

Operational conditions

Operating temperature (T-T): -5 - 45 °C

Weight & dimensions

Dimensions (WxDxH): 56 x 134 x 33 mm

Packaging content

Feature: Power cord included
Feature: Quick installation guide

Packaging data

Package width: 140 mm
Package depth: 160 mm
Package height: 50 mm
Package weight: 863 g
Package volume: 1108 cm³

Logistics data

Harmonized System (HS) code: 85044095
UK Trade Tariff code: 85176200
Master (outer) case width: 315 mm
Master (outer) case length: 475 mm
Master (outer) case height: 340 mm
Master (outer) case gross weight: 17.3 kg
Country of origin: China
