DeLOCK 89641 interface cards / adapter

DeLOCK 89641. Host interface: PCIe, Output interface: Serial, Expansion card form factor: Low-profile. Product colour: Green, Purpose: PC. Data bits: 5, 6, 7, 8, 9, Stop bits: 1, 1.5, 2. Width: 63 mm, Depth: 72 mm, Height: 10 mm

The PCI Express card by Delock expands a PC by two external serial RS-232 ports. Devices such as scanners, protocol converters, POS systems, infrared -, IoT - devices etc. and different modes can be used. By using the included low profile brackets, the PCI Express card can be also installed into a Mini-PC.

Ports & interfaces

Host interface: PCIe
Output interface: Serial
Expansion card form factor: Low-profile
Expansion card standard: PCIe 2.0
Serial interface type: RS-232

Design

Feature: Internal
Product colour: Green
Purpose: PC

Features

Data bits: 5, 6, 7, 8, 9
Stop bits: 1, 1.5, 2

Operational conditions

Operating temperature (T-T): 0 - 70 °C

System requirements

Windows operating systems supported: Yes

Weight & dimensions

Width: 63 mm
Depth: 72 mm
Height: 10 mm

Logistics data

Harmonized System (HS) code: 84733020
