DeLOCK 81473 network antenna

DeLOCK 5G LTE GNSS WiFi 6 Antenna SMA plug 1.1 - 4.0 dBi omnidirectional with connection cable ULA100 1 m roof mounting outdoor black. Antenna gain level (max): 4 dBi, Frequency band: 0.617 - 0.96, 1.166 - 1.61, 1.71 - 2.2, 2.3 - 2.69, 3.3 - 5.925 GHz, Impedance: 50 Ω. Antenna type: Omni-directional antenna, Antenna connector type: SMA, Polarization: Linear, vertical. Depth: 77 mm, Diameter: 4.5 cm, Weight: 135 g. Package type: Box. Quantity per pack: 1 pc(s)
This 5G LTE GNSS WiFi 6 antenna by Delock allows the usage of different 5G LTE bands inside and outside. It is completely compatible to GSM, UMTS, LTE, ZigBee, Z-Wave, NB-IoT, WiFi 6, Bluetooth, ISM and LoRa.
5G the new mobile radio standard
5G unlike its predecessors LTE (4G) and UMTS (3G) will use more and wider frequency spectrums. The 5G standard promises more throughput, capacity and low latency.

Performance

Frequency band: 0.617 - 0.96, 1.166 - 1.61, 1.71 - 2.2, 2.3 - 2.69, 3.3 - 5.925 GHz
Impedance: 50 Ω
Antenna gain level (max): 4 dBi
Wi-Fi standards: Wi-Fi 6 (802.11ax)

Features

Antenna type: Omni-directional antenna
Antenna connector type: SMA
Polarization: Linear, vertical
Voltage Standing Wave Ratio (VSWR): 3.5 - 5.0
Product colour: Black
Housing material: Polycarbonate (PC)
International Protection (IP) code: IP67
Cable length: 1 m
Purpose: Outdoor

Operational conditions

Operating temperature (T-T): -40 - 85 °C

Weight dimensions

Depth: 77 mm
Diameter: 4.5 cm
Weight: 135 g

Packaging data

Package type: Box

Packaging content

Quantity per pack: 1 pc(s)

Logistics data

Country of origin: Taiwan
