DeLOCK 81472 network antenna

DeLOCK 4G MIMO Dual Band WiFi 6 Antenna 2 x SMA + 1 x RP-SMA plug ULA100 1 m screw mounting outdoor white. Antenna gain level (max): 4.5 dBi, Frequency band: 0.698 - 0.791, 0.824 - 0.96, 1.71 - 2.17, 2.3 - 2.7, 2.4 - 2.5, 5.15 - 5.875 GHz, Impedance: 50 Ω. Antenna type: MIMO directional antenna, Antenna connector type: 2x SMA/RP-SMA, Polarization: Linear, vertical. Height: 50 mm, Diameter: 7.8 cm, Weight: 209 g. Package type: Box. Quantity per pack: 1 pc(s)
This antenna by Delock allows the usage of different 4G and WLAN bands outdoors. It is completely compatible to GSM, UMTS, 4G, ZigBee, DECT, Z-Wave, NB-IoT, Dual Band WLAN, Bluetooth, ISM, MIMO and LoRa 868 MHz / 915 MHz.

Performance

Frequency band: 0.698 - 0.791, 0.824 - 0.96, 1.71 - 2.17, 2.3 - 2.7, 2.4 - 2.5, 5.15 - 5.875 GHz
Impedance: 50 Ω
Antenna gain level (max): 4.5 dBi
Wi-Fi standards: Wi-Fi 6 (802.11ax)

Features

Antenna type: MIMO directional antenna
Antenna connector type: 2x SMA/RP-SMA
Polarization: Linear, vertical
Product colour: White
Housing material: Polycarbonate (PC)
International Protection (IP) code: IP67
Cable length: 1 m
Purpose: Outdoor

Operational conditions

Operating temperature (T-T): -40 - 85 °C

Weight dimensions

Height: 50 mm
Diameter: 7.8 cm
Weight: 209 g

Packaging data

Package type: Box

Packaging content

Quantity per pack: 1 pc(s)

Logistics data

Country of origin: Taiwan
