D-Link DMC-G01LC / E network media converter

D-Link DMC-G01LC/E. Maximum data transfer rate: 1000 Mbit/s, Networking standards: IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, Ethernet interface type: Gigabit Ethernet. Mean time between failures (MTBF): 506711 h. Product colour: Grey. Fiber optic connector: SFP, Connectivity technology: Wired. Input voltage: 230 - 240 V, Output voltage: 5 V, Output current: 1 A

D-Link's DMC-G01LC standalone media Converter turns a copper Ethernet link into a fiber link, allowing for an ultra-fast, long distance connection. Installation of a standalone media converter is simple, and allows you to tap into fiber speeds with ease. Instead of requiring an investment in an entire chassis, a standalone media converter provides the same high-quality conversion on a unit-by-unit basis. You can save space and cut costs while still extending your network over long distances of 10 km and beyond on a fiber optic line.

SFP Optical Transceivers for Maximum Flexibility
The fiber side of the DMC-G01LC utilizes a 100/1000 SFP port for maximum flexibility. Using the appropriate SFP transceiver (purchased separately) it can support either multimode or single-mode fiber, varying wavelengths, and speeds of either 100 Mbps or 1000 Mbps.

10/100/1000 Copper Speeds
The copper side of the DMC-G01LC auto-negotiates to 10Mbps, 100Mbps or 1000Mbps, ensuring the connection functions at the highest possible speed while remaining compatible with the link partner. It supports auto MDI/MDIX, half/full duplex operation at 10/100 Mbps and full duplex operation at 1000 Mbps.

Plug & Play
The DMC-G01LC supports standard technologies that makes it easy to operate, like 802.3u. 802.3x and 802.3ab. There's no management software to configure - simply connect the power, connect the cables, and start converting.

Network

Maximum data transfer rate: 1000 Mbit/s
Networking standards: IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Auto MDI/MDI-X

Performance

Mean time between failures (MTBF): 506711 h

Features

LED indicators: Yes
Product colour: Grey

Ports & interfaces

Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: SFP
Feature: DC-in jack

Power

Input voltage: 230 - 240 V
Output voltage: 5 V
Output current: 1 A

Weight & dimensions

Width: 70 mm
Depth: 95 mm
Height: 25 mm

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Packaging data

Package width: 101 mm
Package depth: 134 mm
Package height: 95 mm
Package weight: 358 g

Certificates

Safety: LVD, UL/cUL
Certification: CE, FCC, VCCI, BSMI

Logistics data

Shipping (inner) case length: 50.4 cm
Shipping (inner) case width: 29.4 cm
Shipping (inner) case height: 23.6 cm
Shipping (inner) case net weight: 7.16 kg
Products per shipping (inner) case: 20 pc(s)
Pallet gross weight (air): 341.1 kg
Master (outer) cases per pallet (air): 40 pc(s)
Products per pallet (air): 800 pc(s)
Pallet gross length: 110 cm
Pallet gross width: 120 cm
Pallet height (air): 131 cm
Pallet gross weight (sea): 534.6 kg
Master (outer) cases per pallet (sea): 64 pc(s)
Products per pallet (sea): 1280 pc(s)
Pallet height (sea): 2.02 m
Shipping (inner) case gross weight: 8.04 kg
Harmonized System (HS) code: 85176990
