Conceptronic EMRICK07G interface cards / adapter

Conceptronic EMRICK 2-Port USB 3.2 Gen 2 Type-C PCIe Card. Host interface: PCIe, Output interface: USB 3.2 Gen 2 (3.1 Gen 2), Expansion card standard: PCI 2.0. Product colour: Green, Purpose: PC, Country of origin: China. Chipset: ASM1142, Data transfer rate (max): 10 Gbit/s. Windows operating systems supported: Windows 7 Ultimate x64, Windows 10, Windows 7 x64, Windows 10 Education, Windows 8, Windows 10.... Width: 58 mm, Depth: 80 mm, Height: 20 mm

This PCI Express Card allows you to easily add 2 extra SuperSpeed USB 3.2 Gen 2 ports to your desktop computer. It has a maximum data speed of 10Gbs, which makes it very fast and capable of copying large files or documents to and from your desktop computer. Simply place the USB 3.2 Gen 2 PCI Express Card in the Express Card slot of your computer, install the included drivers and you are right to go!

Ports & interfaces

Host interface: PCIe
Output interface: USB 3.2 Gen 2 (3.1 Gen 2)
Expansion card standard: PCI 2.0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
Internal SATA ports quantity: 1
SATA power connector type: SATA 15-pin

Design

Feature: Internal
Product colour: Green
Purpose: PC
Feature: Hot-swap
Country of origin: China

Features

Chipset: ASM1142
Data transfer rate (max): 10 Gbit/s
Feature: UASP support

System requirements

Linux operating systems supported: Yes

Weight & dimensions

Width: 58 mm
Depth: 80 mm
Height: 20 mm
Weight: 32 g

Packaging data

Feature: Mounting brackets included
Feature: Drivers included
Feature: Quick installation guide
Package width: 125 mm
Package depth: 175 mm
Package height: 30 mm
Package weight: 90 g
Package type: Box

Logistics data

Harmonized System (HS) code: 84733020
Products per master (outer) case: 30 pc(s)
Master (outer) case width: 340 mm
Master (outer) case length: 205 mm
Master (outer) case height: 405 mm
Master (outer) case gross weight: 2.7 kg
