Cisco FPR1010-ASA-K9 hardware firewall

Cisco Secure Firewall: Firepower 1010 Security Appliance with ASA Software, 8 Gigabit Ethernet (GbE) Ports, Up to 2 Gbps Throughput, 90-Day Limited Warranty (FPR1010-ASA-K9). Firewall throughput: 2 Gbit/s, IPSec VPN throughput: 0.5 Gbit/s. Internal memory: 8096 MB, Internal memory type: DDR4, Processor family: Intel. Connectivity technology: Wired, Console port: RJ-45, Remote management port: RJ-45 (Gigabit). Storage media type: SSD, Storage drive interface: Serial ATA, Total storage capacity: 200 GB. Form factor: 1U

The Cisco Secure Firewall with the Firepower 1010 appliance and ASA software provides robust, proven Layer 3 and 4 security control. It includes Power-over-Ethernet and switchport capability for maximum flexibility, support for advanced remote access VPN termination, and BGP and OSPF routing functions. When Layer 7 application control and advanced threat defence are also required, select instead the Firepower 1010 appliance with FTD software.

Data transmission

Firewall throughput: 2 Gbit/s
IPSec VPN throughput: 0.5 Gbit/s
Maximum firewall connections: 100000
Maximum firewall connections per second: 25000

Performance

Feature: Built-in processor
Internal memory: 8096 MB
Internal memory type: DDR4
Processor family: Intel
Processor cores: 4
Feature: Reset button

Ports & interfaces

Connectivity technology: Wired
Gigabit Ethernet (copper) ports quantity: 8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Console port: RJ-45
Number of console ports: 1
Remote management port: RJ-45 (Gigabit)

Storage

Storage media type: SSD
Storage drive interface: Serial ATA
Total storage capacity: 200 GB
SSD capacity: 200 GB

Design

Feature: Rack mounting
Form factor: 1U

Power

Power supply: 30 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -25 - 70 °C
Storage relative humidity (H-H): 10 - 90%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 4570 m

Weight & dimensions

Width: 194.4 mm
Depth: 205 mm
Height: 46.2 mm
Weight: 1.36 kg

Packaging data

Package width: 698.5 mm
Package height: 317.5 mm
Package depth: 812.8 mm
Package weight: 2.95 kg

Other features

Firewall throughput: 2000 Mbit/s

Logistics data

Country of origin: Mexico
Quantity per pack: 1 pc(s)
Harmonized System (HS) code: 85176990
