Cisco FPR1140-ASA-K9 hardware firewall

Cisco Secure Firewall: Firepower 1140 Security Appliance with ASA Software, 8-Gigabit Ethernet (GbE) Ports, 4 SFP Ports, Up to 6 Gbps Throughput, 90-Day Limited Warranty (FPR1140-ASA-K9). Firewall throughput: 2.2 Gbit/s, IPSec VPN throughput: 1.2 Gbit/s. Processor family: Intel. Supported network protocols: SMTP. Connectivity technology: Wired, Console port: RJ-45. Storage media type: SSD, SSD capacity: 200 GB

The Cisco Secure Firewall with ASA software provides robust, proven Layer 3 and 4 security control. Ideal for small and medium-sized offices, this 1RU firewall includes support for advanced remote access VPN termination, plus BGP and OSPF routing functions. When Layer 7 application control and advanced threat defence are also required, select instead the Firepower 1140 appliance with FTD software.

Data transmission

Firewall throughput: 2.2 Gbit/s
IPSec VPN throughput: 1.2 Gbit/s
Maximum firewall connections: 400000
Maximum firewall connections per second: 100000

Performance

Feature: Built-in processor
Processor family: Intel
Processor cores: 16

Security

Feature: Stateful Packet Inspection (SPI)

Protocols

Supported network protocols: SMTP

Management features

Feature: URL filtering

Ports & interfaces

Connectivity technology: Wired
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 8
Console port: RJ-45
Number of console ports: 1
SFP module slots quantity: 4

Storage

Storage media type: SSD
SSD capacity: 200 GB

Design

Feature: Rack mounting
Form factor: 1U

Power

AC input voltage: 100-240 V
AC input frequency: 50 - 60 Hz
Input current: 2 A
Power consumption (max): 100 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -25 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 90%
Operating altitude: 0 - 3000 m

Weight & dimensions

Width: 268.7 mm
Depth: 436.9 mm
Height: 43.7 mm

Packaging data

Package width: 990.6 mm
Package height: 457.2 mm
Package depth: 1409.7 mm
Package weight: 5.78 kg

Other features

Firewall throughput: 2200 Mbit/s

Logistics data

Country of origin: Mexico
Quantity per pack: 1 pc(s)
Harmonized System (HS) code: 85176990
