Cisco AIR-ANT2566P4W-RS network antenna

Cisco Aironet Dual-Band Directional Wi-Fi Patch Antenna, 6 dBi (2.4 GHz)/6 dBi (5 GHz), 4 Ports, Wall Mount, Self-Identifying, 1-Year Limited Hardware Warranty (AIR-ANT2566P4W-RS=). Antenna gain level (max): 6 dBi, Frequency band: 2.4/5 GHz. Antenna connector type: RP-TNC, Polarization: Linear polarization, Voltage Standing Wave Ratio (VSWR): 2:1. Width: 280 mm, Depth: 160 mm, Height: 30 mm. Package width: 244.6 mm, Package depth: 333.5 mm, Package height: 79.5 mm. Quantity per pack: 1 pc(s)

The Cisco Aironet AIR-ANT2566P4W-RS= Dual-Band Directional Wi-Fi Patch Antenna is designed with improved performance in mind. It directs the energy it receives from the transmitter to provide more energy in one direction and less in other directions. This FCC-approved patch antenna includes circuitry to enable self-identification of the antenna by the Cisco Catalyst 9100 Access Points.

Performance

Frequency band: 2.4/5 GHz
Antenna gain level (max): 6 dBi

Features

Antenna connector type: RP-TNC
Polarization: Linear polarization
Voltage Standing Wave Ratio (VSWR): 2:1

Weight & dimensions

Width: 280 mm
Depth: 160 mm
Height: 30 mm

Packaging data

Package width: 244.6 mm
Package depth: 333.5 mm
Package height: 79.5 mm
Package weight: 798.19 g

Packaging content

Quantity per pack: 1 pc(s)

Logistics data

Country of origin: Malaysia
