Cisco AIR-ANT2547VG-N network antenna

Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 4 dBi (2.4 GHz)/7 dBi (5 GHz), N-Type Male Connector, Direct Mount, 1-Year Limited Hardware Warranty (AIR-ANT2547VG-N=). Antenna gain level (max): 7 dBi, Frequency band: 2.4/5 GHz, Gain: 4 / 7 dBi. Antenna type: Omni-directional antenna, Antenna connector type: N-type, Connector gender: Male. Height: 282 mm, Diameter: 3.17 cm, Weight: 170 g. Package width: 152.4 mm, Package depth: 482.6 mm, Package height: 50.8 mm. Quantity per pack: 1 pc(s)

The Cisco Aironet AIR-ANT2547VG-N= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved coverage and performance in mind. This FCC-approved omnidirectional antenna provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions from the antenna is required.

Performance

Frequency band: 2.4/5 GHz
Gain: 4 / 7 dBi
Antenna gain (2.4 GHz): 4 dBi
Antenna gain (5 GHz): 7 dBi
Impedance: 50 Ω
Bandwidth note: 2400 - 2483 , 5150 - 5875 MHz
Horizontal beam width (2.4 GHz): 30°
Horizontal beam width (5 GHz): 14°
Antenna gain level (max): 7 dBi

Features

Antenna type: Omni-directional antenna
Antenna connector type: N-type
Connector gender: Male
Voltage Standing Wave Ratio (VSWR): 2:1
Product colour: Grey
Protection features: Dust resistant, Splash proof, Water resistant
International Protection (IP) code: IP67
Feature: Waterproof
Survival wind speed: 265 km/h
Purpose: Outdoor

Operational conditions

Operating temperature (T-T): -40 - 85 °C

Weight & dimensions

Height: 282 mm
Diameter: 3.17 cm
Weight: 170 g

Packaging data

Package width: 152.4 mm
Package depth: 482.6 mm
Package height: 50.8 mm
Package weight: 340.14 g

Packaging content

Quantity per pack: 1 pc(s)
Feature: Manual

Logistics data

Harmonized System (HS) code: 85177100
Country of origin: China
