Cisco AIR-ANT2524DW-RS network antenna

Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), 1 Port, Direct Mount, RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-RS=). Antenna gain level (max): 4 dBi, Frequency band: 2.4/5 GHz, Antenna gain (2.4 GHz): 2 dBi. Antenna type: Omni-directional antenna, Antenna connector type: RP-TNC, Connector gender: Male. Package width: 152.4 mm, Package depth: 184.2 mm, Package height: 49.3 mm. Quantity per pack: 1 pc(s). Country of origin: Malaysia
The Cisco Aironet AIR-ANT2524DW-RS= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved performance in mind. It provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions is required. This FCC-approved omnidirectional antenna includes circuitry to enable self-identification of the antenna by the Cisco Catalyst 9100 Access Points.

Performance

Frequency band: 2.4/5 GHz
Antenna gain (2.4 GHz): 2 dBi
Antenna gain (5 GHz): 4 dBi
Impedance: 50 Ω
Horizontal beam width (2.4 GHz): 63°
Horizontal beam width (5 GHz): 39°
Antenna gain level (max): 4 dBi

Features

Antenna type: Omni-directional antenna
Antenna connector type: RP-TNC
Connector gender: Male
Polarization: Dual polarization
Voltage Standing Wave Ratio (VSWR): 2:1
Product colour: White
Purpose: Indoor
Compatible products: Cisco Catalyst 9115AX, 9120AX, 9130AX

Operational conditions

Operating temperature (T-T): -20 - 60 °C
Storage temperature (T-T): -40 - 85 °C

Packaging data

Package width: 152.4 mm
Package depth: 184.2 mm
Package height: 49.3 mm
Package weight: 108.84 g

Packaging content

Quantity per pack: 1 pc(s)
Feature: Quick installation guide
Feature: Manual

Logistics data

Country of origin: Malaysia
