Cisco AIR-ANT2524DW-R network antenna

Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), White Dipole (1 Port), RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-R=). Antenna gain level (max): 4 dBi, Frequency band: 2.4/5 GHz, Antenna gain (2.4 GHz): 2 dBi. Antenna type: Omni-directional antenna, Antenna connector type: RP-TNC, Connector gender: Male. Width: 21 mm, Depth: 168.5 mm, Weight: 38.5 g. Package width: 152.4 mm, Package depth: 184.2 mm, Package height: 49.3 mm. Quantity per pack: 1 pc(s)

The Cisco Aironet AIR-ANT2524DW-R= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved coverage and performance in mind. This FCC-approved omnidirectional antenna provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions from the antenna is required.

Performance

Frequency band: 2.4/5 GHz
Antenna gain (2.4 GHz): 2 dBi
Antenna gain (5 GHz): 4 dBi
Impedance: 50 Ω
Horizontal beam width (2.4 GHz): 63°
Horizontal beam width (5 GHz): 39°
Antenna gain level (max): 4 dBi

Features

Antenna type: Omni-directional antenna
Antenna connector type: RP-TNC
Connector gender: Male
Voltage Standing Wave Ratio (VSWR): 2:1
Product colour: Grey
Purpose: Indoor

Operational conditions

Operating temperature (T-T): -20 - 60 °C
Storage temperature (T-T): -40 - 85 °C

Weight & dimensions

Width: 21 mm
Depth: 168.5 mm
Weight: 38.5 g

Packaging data

Package width: 152.4 mm
Package depth: 184.2 mm
Package height: 49.3 mm
Package weight: 136.05 g

Packaging content

Quantity per pack: 1 pc(s)

Logistics data

Harmonized System (HS) code: 85177100
Country of origin: China

Other features

Frequency range: 2.4 - 2.5GHz, 5.15 - 5.85GHz
