BlueOptics MMA1T00-HS-BO network transceiver module

BlueOptics MMA1T00-HS-BO. SFP transceiver type: Fiber optic, Maximum data transfer rate: 200 Mbit/s, Interface type: QSFP56. Product colour: Aluminium. Weight: 40 g. Quantity per pack: 1 pc(s). Package weight: 50 g

Superior Performance
MMA1T00-HS 200GBASE-SR4 QSFP56 transceiver with MPO/MTP connection according to MSA standards compatible with NVIDIA from the BlueOptics brand. The MMA1T00-HS 200GBASE-SR4 MPO/MTP QSFP56 compatible with NVIDIA has a receiving function (receiver with 850nm) and a transmitting function (transmitter with 850nm) for the transmission of optical signals via multimode fiber, taking the respective transmission protocol into account. This MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 is suitable for the use in all common hardware platforms (such as switches, routers, storage systems, load balancers, measuring devices, etc.) from NVIDIA, which also support the official NVIDIA MMA1T00-HS 200GBASE-SR4 MPO/MTP QSFP56.

Compatibility and Quality
In order to guarantee 100% compatibility and functionality, all MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 are tested for use in the respective NVIDIA hardware and use adapted compatible software. Every MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 from the BlueOptics brand is produced according to the firmly defined MSA standards like the official NVIDIA MMA1T00-HS transceiver and includes individual components from well-known traditional companies for data communication technology, such as high-quality lasers (e.g. from Broadcom or Lumentum) and high-quality ICs (e.g. from Mindspeed or Analog Devices). This preselection of the world's best components for optical transceiver modules leads to an above-average service life of all MMA1T00-HS compatible BlueOptics 200GBASE-SR4 MPO/MTP QSFP56 of more than 10 years.

Wide Range of Applications
MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 from BlueOptics support all common applications for optical data transmission and are suitable for the use in switches, routers, storage systems and other hardware solutions that support the official NVIDIA MA-SFP-200GB -SR 200GBASE-SR4 MPO/MTP QSFP56 according to the manufacturers data sheet. The Blueoptics MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 is an alternative replacement for official NVIDIA MMA1T00-HS 200GBASE-SR4 MPO/MTP QSFP56. Therefore, from now on, rely on MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 from BlueOptics with an optimal price-performance ratio and convince yourself of their quality and functionality. The BlueOptics MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 support all common applications and offer a full range of functions.

Data Transmission at the Speed of Light
Fiber optic connections for optical data transmission are not susceptible to electromagnetic interference (EMI) and offer the possibility of a wide range of variations in terms of bandwidth updates. With MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 from BlueOptics you can increase your bandwidth and reduce latency with the highest availability without any loss. MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 send and receive signals simultaneously using optical laser transmission technology via one fiber optic each and have an MPO/MTP connection. The optimal connection is made via the matching BlueOptics fiber optic patch cables, for example to a patch panel or directly to another MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 transceiver from BlueOptics. This allows you to achieve the optimal range and quality of your fiber optic connection.

Error Analysis with Digital Diagnostics
Make troubleshooting, maintenance and monitoring in your network easier with the Digital Diagnostics Monitoring (DDM) / Digital Optical Monitoring (DOM) interface integrated into the MMA1T00-HS compatible with NVIDIA 200GBASE-SR4 MPO/MTP QSFP56. With the help of the digital diagnostic function, compliant with MSA SFF-8472, MMA1T00-HS 200GBASE-SR4 MPO/MTP QSFP56 compatible with NVIDIA can output the following information in real time: voltage supply, laser quiescent current, laser output power, laser input power and temperature. This feature of the MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 makes remote maintenance of optical transmission links easier. Please make sure that the DDM / DOM function must also be supported by the respective NVIDIA hardware in which the MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 is used in order to be able to access the features mentioned above.

Maximum Availability
Less maintenance due to long service life. MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 from BlueOptics only use components from market-leading manufacturers for communication technology, such as lasers (e.g. Lumentum or Broadcom) and integrated circuits (e.g. Mindspeed & Analog Devices). For this reason, MMA1T00-HS are designed for above-average operating times of over 3,000,000 MTBF hours. This corresponds to an average lifespan of 10 years and allows you to make your network future-proof. All BlueOptics MMA1T00-HS compatible 200GBASE-SR4 MPO/MTP QSFP56 transceivers provide high availability and reduce the likelihood of failure of critical optical data links in high-speed network systems to an absolute minimum.

Performance

SFP transceiver type: Fiber optic
Maximum data transfer rate: 200 Mbit/s
Interface type: QSFP56
Feature: Multi-mode fiber (MMF) supported
Fiber optic connector: MTP/MPO
Maximum transfer distance: 100 m
Tx wavelength (max): 850 nm
Rx wavelength (max): 850 nm

Features

Product colour: Aluminium

Operational conditions

Operating temperature (T-T): 0 - 70 °C

Weight & dimensions

Weight: 40 g

Packaging content

Quantity per pack: 1 pc(s)

Packaging data

Package weight: 50 g

Logistics data

Warranty period: 5 year(s)
