Axis Q1800-LE

Axis Q1800-LE. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.06 lx, Angle of rotation: 270°, Horizontal field of view (thermal module): 38 - 2.3°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Sensor type (panoramic camera): CMOS, Signal-to-Noise Ratio (SNR) (panoramic camera): 55 dB

This purpose-tuned camera is ideal for traffic surveillance and smart city initiatives - enabling you to capture sharp license plate images 24/7. Made for 3rd party LPR software, it can help law enforcement agencies improve road safety and gather valuable intelligence.

Extraordinary accuracy 24/7
Designed to capture license plates with exceptional clarity and sharpness, this purpose-tuned camera comes preconfigured with advanced algorithms focusing solely on license plates. This ensures the required pixel density for accurate identification - with practically no setup required! It can capture plates at speeds up to 250 km/h (155 mph) in single lanes and from distances of up to 100 m (328 ft) during daylight. In pitch darkness, the camera captures license plate images at up to 50 m (164 ft), and up to 100 m (328 ft) with the optional accessory AXIS T90D20 IR-LED Illuminator delivering unmatched, reliable performance day and night.

Do it your way
AXIS Q1800-LE is fully compatible with edge- or server-based LPR software from any leading third-party vendor, giving you the freedom to choose the license plate recognition analytics that best suit your needs. Built on the Axis open platform, it integrates seamlessly with most third-party video management software (VMS) and supports a wide range of third-party applications and analytics. Plus, with various installation accessories available, this camera offers flexible mounting options, making it an ideal solution for any deployment.

Ready for anything
This purpose-tuned camera ensures accurate license plate capture 24/7 with minimal setup. Robust and weatherproof, it ensures durability in the toughest conditions. It includes an extra-long weathershield that can withstand hurricane-force winds of up to 60 m/s (134 mph) and resist harsh weather impacts (IK10-rated casing, IK08-rated front glass, and IP66- and NEMA 4X-rated). Plus, electronic image stabilization ensures stable images in situations where the camera is subject to vibrations. What's more, the discreet gray color housing and black weathershield blend right into any traffic environment.

Performance

Type: IP security camera
Placement supported: Outdoor
Connectivity technology: Wired
Feature: PTZ control
PTZ modes: Digital PTZ
Feature: Preset points
Feature: Wide Dynamic Range (WDR)
Feature: Day/night mode
Feature: Infrared (IR) cut-off filter
Certification: UL/cUL, BIS, UKCA, CE, KC, VCCI, RCM

Design

Form factor: Bullet
Mounting type: Wall
Product colour: Black
Housing material: Aluminium, Glass
Protection features: Impact resistant, Vandal proof, Weather resistant
International Protection (IP) code: IP66
IK code: IK08, IK10

Camera

Minimum illumination: 0.06 lx
Angle of rotation: 270°
Horizontal field of view (thermal module): 38 - 2.3°
Lens viewing angle, horizontal: 22 - 1.3°
Tilt angle range: 0 - 90°
Pan range: -180 - 180°
Camera pixel size: 2.9 µm
Camera shutter speed: 1/111000 - 2 s

Image sensor

Number of sensors: 1
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS

Panoramic camera

Sensor type (panoramic camera): CMOS
Signal-to-Noise Ratio (SNR) (panoramic camera): 55 dB

Lens system

Number of lenses: 1
Focal length range: 7 - 138 mm
Feature: Auto focus
Identify distance: 1.2 m
Detect distance (wide): 96.7 m
Detect distance (tele): 1884.2 m
Observe distance (wide): 38.4 m
Observe distance (tele): 747.7 m
Recognize distance (wide): 19.3 m
Recognize distance (tele): 376.8 m
Identify distance (wide): 9.7 m
Identify distance (tele): 188.4 m
Closest focusing distance: 1.2 m

Night vision

Feature: Night vision
Night vision distance: 100 m
B/W night vision distance: 50 m
LED type: IR
Infra-red wavelength: 850 nm

Video

Maximum resolution: 1920 x 1080 pixels
Video formats supported: AVC, H.264, H.265, M-JPEG
Supported graphics resolutions: 160 x 120, 320 x 180, 1400 x 1050 (SXGA+), 1920 x 1080 (HD 1080)
Supported video modes: 1080p
Frame rate: 90 fps
Feature: Video streaming
Feature: Noise reduction
Noise reduction technology: 2D noise reduction, 3D noise reduction
Image quality adjustment: Brightness, Contrast, Saturation, Sharpness
Feature: Text caption overlay
Feature: Image stabilizer
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Audio

Feature: Built-in speaker(s)
Audio system: 2-way
Audio formats supported: AAC-LC, ADPCM, LPCM, OPUS, PCM
Sample rate: 48 kHz
Signal-to-Noise Ratio (SNR): 55 dB
Feature: Audio detection

Network

Feature: Ethernet LAN
Networking standards: IEEE 802.3af, IEEE 802.3at
Streaming method: Multicast

Storage

Feature: Card reader integrated
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory: 8192 MB
Internal memory: 2048 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
Feature: Microphone in
Feature: Terminal block port
Feature: DC-in jack

Security

Feature: Password protection
Feature: Video motion detection
Feature: Active tampering alarm
Security algorithms: HTTPS
Intelligent Video Surveillance (IVS) system features: Human detection, Line crossing detection, Moving object, Vehicle detection
Feature: Pixel counter
Feature: Digest authentication

Management features

Feature: Remotely operated

Power

Power source type: PoE
Power consumption (typical): 11 W
Power consumption (max): 29 W

Operational conditions

Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 100%
Storage relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 183 mm
Depth: 464 mm
Height: 183 mm
Weight: 3.2 kg

Sustainability

Compliance certificates: Electromagnetic Compatibility (EMC), Trade Agreements Act (TAA)

Packaging content

Number of cameras: 1
Cables included: LAN (RJ-45)
Feature: Manual

Other features

Doesn't contain: BFR, CFR
