Axis 03275-001 security camera

Axis 03275-001. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Minimum illumination: 0.05 lx, Angle of rotation: 350°, Lens viewing angle, horizontal: 124°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Fixed focal length: 3.76 mm

This cost-efficient mini dome delivers great 4K image quality in challenging light conditions. It comes with AI-powered video and audio analytics preinstalled. Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device.

Capture great 4K image quality with this discreet camera
AXIS M3098-V delivers great 4K image quality even in challenging light conditions. Forensic WDR ensures good exposure when there's both dark and light areas in the scene and sharp color images in low light. And Lightfinder delivers true-to-life colors even in low light. With a 124° horizontal field of view, it offers wide-area coverage. In addition, corridor format ensures the video is perfectly adapted to monitored corridors. Furthermore, Axis Zipstream with support for H.264 and H.265 significantly reduces bandwidth and storage requirements without compromising image quality.

Leverage AI-powered video and audio analytics
This AI-based camera runs advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans. With an acoustic sensor and AXIS Audio Analytics preinstalled, it can detect key sounds, such as screams, shouts, coughing fits, as well as changes in sound level. This IP-device can also trigger automated responses on other devices. What's more, this camera generates metadata that can be gathered and visualized in a dashboard for valuable insights.

Save more while staying secure
AXIS M3098-V offers flexible and discreet installation on walls and ceilings, and the casing simply snaps on - no screws required. It comes with a factory-focused fixed field of view, so there's no manual focusing required. In addition, direct installation view lets installers see and adjust the camera view in AXIS Installer application on smartphones and tablets using Bluetooth®, without accessing the network. This helps ensure faster, simpler, and more cost-efficient installations.* Furthermore, Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operations.

Performance

Type: IP security camera
Placement supported: Indoor
Connectivity technology: Wired
Feature: PTZ control
Feature: Wide Dynamic Range (WDR)
Feature: Infrared (IR) cut-off filter

Design

Form factor: Dome
Mounting type: Ceiling/wall
Product colour: White
International Protection (IP) code: IP42
IK code: IK08

Camera

Feature: Camera pan control
Feature: Camera tilt control
Minimum illumination: 0.05 lx
Feature: Rotating
Angle of rotation: 350°
Lens viewing angle, horizontal: 124°
Lens viewing angle, vertical: 66°
Tilt angle range: -10 - 57°
Pan range: -175 - 175°
Camera shutter speed: 1/66000 - 1/5 s

Image sensor

Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Sensor type: CMOS

Lens system

Number of lenses: 1
Maximum aperture number: 2
Fixed focal length: 3.76 mm

Night vision

Feature: Night vision
LED type: IR

Video

Maximum resolution: 3840 x 2160 pixels
Total megapixels: 8 MP
Video compression formats: H.264, H.265
Frame rate: 15 fps

Audio

Feature: Audio detection

Network

Feature: Ethernet LAN
Feature: Quality of Service (QoS) support

Storage

Feature: Card reader integrated
Flash memory: 8000 MB
RAM capacity: 2000 MB

Security

Feature: Privacy protection
Intelligent Video Surveillance (IVS) system features: Human detection, Vehicle detection, Moving object, Line crossing detection

Power

Power source type: PoE

Operational conditions

Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 85%
Storage relative humidity (H-H): 5 - 95%

Weight & dimensions

Weight: 194 g

Packaging content

Number of cameras: 1
