Axis 02484-001 security camera

Axis 02484-001. Placement supported: Indoor outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Black, White, Form factor: Box. Minimum illumination: 0.17 lx, Lens viewing angle, horizontal: 112°, Lens viewing angle, vertical: 82°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Focal length range: 2.8 - 13 mm
AXIS M1137 Mk II is an affordable, compact box camera that's easy to install and operate. It supports PoE and redundant DC power to ensure your data is safeguarded in the event of a power outage. Featuring Axis Lightfinder and Axis Forensic WDR, it delivers true colors and great details in challenging light or near darkness. The camera's CS-mount enables flexibility for exchangeable lenses. And a built-in microphone allows you to record video with sound. With AXIS Object Analytics preinstalled, it's possible to detect and classify humans and vehicles. Furthermore, Axis Zipstream with H.264/H.265 significantly lowers bandwidth and storage requirements.

Performance

Placement supported: Indoor outdoor
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes

Design

Form factor: Box
Mounting type: Wall
Product colour: Black, White

Camera

Minimum illumination: 0.17 lx
Lens viewing angle, horizontal: 112°
Lens viewing angle, vertical: 82°
Camera shutter speed: 1/33500 - 1/5 s

Image sensor

Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Sensor type: CMOS

Lens system

Focal length range: 2.8 - 13 mm

Night vision

Night vision: Yes

Video

Maximum resolution: 2592 x 1944 pixels
Total megapixels: 5 MP
Video formats supported: H.264, H.265
Video compression formats: MPEG4
Supported graphics resolutions: 160 x 120
Frame rate: 30 fps

Network

Networking standards: IEEE 802.3af, IEEE 802.3at

Storage

Flash memory: 512 MB

Power

Power source type: DC, PoE
Power consumption (typical): 4.4 W
Power consumption (max): 6.6 W
Power consumption (Power over Ethernet (PoE)): 4.5 W
DC output voltage: 10, 12, 15, 16, 24, 28

Operational conditions

Operating temperature (T-T): -20 - 50 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 85%
Storage relative humidity (H-H): 5 - 95%

Weight dimensions

Width: 70 mm
Depth: 179 mm
Height: 59 mm
Width (with stand): 70 mm
Depth (with stand): 179 mm
Height (with stand): 179 mm

Packaging content

Number of cameras: 1

Logistics data

Harmonized System (HS) code: 85258900
