Axis 02442-031 security camera

Axis 02442-031. Type: IP security camera, Placement supported: Indoor outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Box. Minimum illumination: 0.05 lx, Camera shutter speed: 1/47500 - 1 s. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Maximum resolution: 2688 x 1512 pixels, Total megapixels: 4 MP, Video compression formats: H.264, H.265
With 4 MP resolution at up to 60 fps, a 1/1.8" sensor, and Lightfinder 2.0, AXIS Q1656-BLE delivers exceptional video quality even in poor light conditions. Based on the latest Axis system-on-chip (SoC), it offers support for advanced features and applications based on deep learning on the edge. And AXIS Object Analytics provides highly nuanced object classification. With built-in cybersecurity features, it prevents unauthorized access and safeguards your system. This outdoor-ready barebone unit comes without lens and mounting for maximum flexibility. Furthermore, it includes power-efficient IR and white LED illumination.

Performance

Type: IP security camera
Placement supported: Indoor outdoor
Connectivity technology: Wired
PTZ control: Yes
PTZ modes: Digital PTZ
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Alarm input/output: Yes
Number of languages: 12
Languages support: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian
Certification: CISPR 24, CISPR 35, EN 55032 Class A, EN 55035,EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2,FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), EN 50121-4,IEC 62236-4, KS C 9832 Class A, KS C 9815, KS C 9835,KS C 9547, RCM AS/NZS CISPR 32 Class A, VCCI Class A

Design

Form factor: Box
Mounting type: Ceiling/wall
Product colour: White
International Protection (IP) code: IP66, IP67
IK code: IK10

Camera

Camera pan control: Yes
Camera tilt control: Yes
Minimum illumination: 0.05 lx
Camera shutter speed: 1/47500 - 1 s

Image sensor

Number of sensors: 1
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Progressive scan: Yes
Sensor type: CMOS

Lens system

Zoom capability: Yes
Number of lenses: 4

Night vision

Night vision: Yes

Video

Maximum resolution: 2688 x 1512 pixels
Total megapixels: 4 MP
Video compression formats: H.264, H.265
Video recording: Yes
Frame rate: 60 fps
Video streaming: Yes
Image quality adjustment: Brightness, Contrast, Saturation
Privacy masking: Yes
Image stabilizer: Yes
Bit rate control: Variable Bit Rate (VBR)

Audio

Audio formats supported: AAC, ADPCM, G.711, G.726, OPUS, PCM
Built-in microphone: Yes
Audio detection: Yes

Network

Ethernet LAN: Yes
Networking standards: IEEE 802.3at
Wi-Fi: No
Bluetooth: No
Quality of Service (QoS) support: Yes

Storage

Built-in HDD: No
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory: 8194 MB
Internal memory: 2048 MB

Ports interfaces

Ethernet LAN (RJ-45) ports: 1

Security

Password protection: Yes
Video motion detection: Yes
Active tampering alarm: Yes
IP address filtering: Yes
Security algorithms: 802.1x RADIUS
HTTPS encryption: Yes
Alert notification type: E-mail
Pixel counter: Yes
Digest authentication: Yes

Power

Power source type: PoE
Power consumption (typical): 11.2 W
Power consumption (max): 25.5 W

Operational conditions

Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 100%
Storage relative humidity (H-H): 5 - 95%

Weight dimensions

Width: 404 mm
Depth: 159 mm
Height: 182 mm
Weight: 4.1 kg

Packaging content

Number of cameras: 1
