Axis 02341-001 security camera

Axis 02341-001. Type: IP security camera, Placement supported: Indoor outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.13 lx, Camera shutter speed: 1/50000 - 1/5 s. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Focal length range: 2.8 - 8 mm
Based on ARTPEC-8, AXIS P1467-LE delivers excellent image quality in 5 MP. It includes a deep learning processing unit enabling advanced features and powerful analytics based on deep learning on the edge. With AXIS Object Analytics preinstalled, it offers detection and classification of humans, vehicles, and types of vehicles. This IP66/IP67, NEMA 4X, and IK10-rated camera can withstand winds up to 50 m/s. Lightfinder 2.0, Forensic WDR, and OptimizedIR, ensure sharp, detailed images under any light conditions. Furthermore, it includes Axis Edge Vault to protect your Axis device ID and simplify authorization of Axis products on your network.

Performance

Type: IP security camera
Placement supported: Indoor outdoor
Connectivity technology: Wired
PTZ modes: Digital PTZ
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Number of languages: 12
Languages support: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian
Certification: EN 55032 Class A, EN 50121-4, IEC 62236-4, EN 55035,EN 61000-3-3, EN 61000-6-1, EN 61000-6-2,FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A),VCCI Class A, RCM AS/NZS CISPR 32 Class A

Design

Form factor: Bullet
Mounting type: Ceiling/wall
Product colour: White
Housing material: Aluminium, Polycarbonate (PC)
International Protection (IP) code: IP66, IP67
IK code: IK10
Weatherproof: Yes

Camera

Minimum illumination: 0.13 lx
Camera shutter speed: 1/50000 - 1/5 s

Image sensor

Number of sensors: 1
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Progressive scan: Yes
Sensor type: CMOS

Lens system

Zoom capability: Yes
Number of lenses: 1
Focal length range: 2.8 - 8 mm

Night vision

Night vision: Yes
Night vision distance: 40 m
LED type: IR
Infra-red wavelength: 850 nm

Video

Maximum resolution: 2592 x 1944 pixels
Total megapixels: 5 MP
Video compression formats: H.264, H.265
Supported graphics resolutions: 1280 x 720 (HD 720)
Supported video modes: 720p
Video recording: Yes
Frame rate: 30 fps
Video streaming: Yes
Flip mirror: Yes
Privacy masking: Yes
Text caption overlay: Yes
Bit rate: Configurable bit rate

Audio

Audio formats supported: AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM
Audio detection: Yes

Network

Ethernet LAN: Yes
Networking standards: IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Supported network protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa, HTTP/2, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SOCKS, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf)
Wi-Fi: No
Bluetooth: No
Quality of Service (QoS) support: Yes

Storage

Built-in HDD: No
Built-in SSD: No
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD
Flash memory: 8000 MB
Internal memory: 2000 MB

Ports interfaces

Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Terminal block port: Yes

Security

Password protection: Yes
Video motion detection: Yes
Active tampering alarm: Yes
IP address filtering: Yes
Security algorithms: 256-bit AES-XTS, EAP-TLS
HTTPS encryption: Yes
Alert notification type: E-mail, Text alert message
Pixel counter: Yes
Digest authentication: Yes

Power

Power source type: PoE
Power consumption (typical): 5.8 W
Power consumption (max): 12.9 W

Operational conditions

Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 100%
Storage relative humidity (H-H): 5 - 95%

System requirements

Windows operating systems supported: Yes

Weight dimensions

Width: 280 mm
Depth: 280 mm
Diameter: 13.2 cm
Weight: 1.2 kg

Packaging content

Number of cameras: 1
Mounting brackets included: Yes
Drilling template included: Yes
Manual: Yes

Other features

Doesn't contain: BFR, PVC
