Axis 01190-001 security camera accessory

Axis 01190-001. Type: Base unit, Placement supported: Universal, Product colour: White. Maximum weight capacity: 2.3 kg, Connecting thread: 3/4". Connectivity technology: Wired. Diameter: 15.7 cm, Height: 53.5 mm, Weight: 750 g
AXIS T94S01P Conduit Back Box is an outdoor-ready, impact resistant (IK10+) back box designed to be mounted behind a wide range of Axis network cameras. It has an ingress-protected (IP66/IP67) compartment for secure storage of connectivity devices. Examples include storing an IP-over-COAX adapter to re-use legacy cabling or a network cable coupler to bridge between rigid and flexible network cables. AXIS T94S01P enables both camera and connectivity device to be safely mounted at the same point, without need for extra cabinet installation (even directly onto junction boxes). The finished installation is both aesthetically pleasing and able to withstand challenging outdoor conditions.

Features

Type: Base unit
Placement supported: Universal
Product colour: White
Housing material: Aluminium
International Protection (IP) code: IP67
Protection features: Vandal proof

Ergonomics

Maximum weight capacity: 2.3 kg
Connecting thread: 3/4"

Ports interfaces

Connectivity technology: Wired

Weight dimensions

Diameter: 15.7 cm
Height: 53.5 mm
Weight: 750 g

Technical details

Compliance certificates: RoHS

Logistics data

Harmonized System (HS) code: 85299020
