ALLNET ALL-MC202P-SFP1-POE network media converter

ALLNET ALL-MC202P-SFP1-POE. Maximum data transfer rate: 1000 Mbit/s, Converter input interface: 10Base-T, 100Base-TX, 1000Base-T, Converter output interface: 1000Base-LX, 1000Base-SX. Fiber mode structure: Multi-mode, Single-mode, Fiber cable diameters supported (core/cladding): 9/125,50/125,62.5/125 µm. Product colour: Black. Fiber optic connector: MiniGBIC, Connectivity technology: Wired. Output voltage: 52 V, Output current: 1.25 A

Network

Maximum data transfer rate: 1000 Mbit/s
Converter input interface: 10Base-T, 100Base-TX, 1000Base-T
Converter output interface: 1000Base-LX, 1000Base-SX
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Flow control support: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Duplex system: Full, Half
Cable types supported: Cat5, Cat5e, Cat6, Fiber

Performance

Fiber mode structure: Multi-mode, Single-mode
Fiber cable diameters supported (core/cladding): 9/125,50/125,62.5/125 µm

Features

Internal: No
LED indicators: Yes
Product colour: Black

Ports interfaces

Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: MiniGBIC
DC-in jack: Yes

Power

Output voltage: 52 V
Output current: 1.25 A
Power over Ethernet (PoE): Yes
External power adapter: Yes

Sustainability

Sustainability compliance: Yes

Weight dimensions

Width: 185 mm
Depth: 134 mm
Height: 35 mm

Operational conditions

Operating temperature (T-T): -20 - 60 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%

Packaging content

AC adapter included: Yes

Certificates

Compliance certificates: CE
Certification: EN61000-4-2(ESD), Level 3EN61000-4-3(RS), Level 3EN61000-4-4(EFT), Level 3EN61000-4-5(Surge), Level 3EN61000-4-6(CS), Level 3EN61000-4-8, 100A/mEN61000-4-12IEC 60068-2-27IEC 60068-2-32IEC 60068-2-6
