ALLNET 222870

ALLNET 222870. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 1000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x. DC input voltage: 44 - 57 V. Power over Ethernet (PoE). Rack mounting, Form factor: DIN rail

Management features

Switch type: Unmanaged
Switch layer: L2
Feature: Web-based management

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 5

Network

Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-TX
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: MAC address auto-learning supported

Data transmission

Switching capacity: 10 Gbit/s
Forwarding rate: 7.4 Mpps
MAC address table: 1000 entries
Feature: Store-and-forward
Packet forwarding rate (1 Gbps): 1488000 pps
Packet forwarding rate (100 Mbps): 148800 pps
Packet forwarding rate (10 Mbps): 14880 pps

Design

Feature: Rack mounting
Form factor: DIN rail
Product colour: White
LED indicators: Yes
Market segment: Business

Power

Power source: PoE
DC input voltage: 44 - 57 V

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE) voltage: 57 V
Power over Ethernet (PoE) power per port: 91 W

Operational conditions

Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 82 mm
Depth: 52 mm
Height: 23 mm
Weight: 55 g

Certificates

Compliance certificates: CE, REACH, RoHS
