ALLNET 212816

ALLNET 212816. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 6. MAC address table: 8000 entries, Switching capacity: 12 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE.... Power over Ethernet (PoE). Wall mountable, Form factor: Desktop/Wall-Mounting

Management features

Switch type: Managed
Feature: Quality of Service (QoS) support

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 6
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 6

Network

Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported: Cat3, Cat4, Cat5, Cat5e
Feature: Port mirroring
Feature: Link aggregation
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Cable length detection
Feature: MAC address auto-learning supported
Feature: MAC address auto-aging supported
Feature: VLAN support

Data transmission

Switching capacity: 12 Gbit/s
Forwarding rate: 8.93 Mpps
MAC address table: 8000 entries
Feature: Store-and-forward
Feature: Jumbo frames support
Jumbo frames: 9216
Packet buffer memory: 4.1 MB

Security

DHCP features: DHCP snooping
Feature: MAC address filtering
MAC address entries: Static MAC address entries

Design

Feature: Stackable
Form factor: Desktop/Wall-Mounting
Product colour: Black
LED indicators: Activity, Link, PoE, Power
Feature: Wall mountable

Performance

Feature: Fanless
Mean time between failures (MTBF): 50000 h

Power

Power source: AC
Power consumption (typical): 60 W

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 1
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 95 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

Width: 168 mm
Depth: 86 mm
Height: 32 mm

Certificates

Compliance certificates: REACH, RoHS
