Neomounts FPMA-W830BLACK TV mount / stand

Neomounts FPMA-W830BLACK Monitor/TV mount wall 10-27" - full motion. Maximum weight capacity: 12 kg, Minimum screen size: 25.4 cm (10"), Maximum screen size: 68.6 cm (27"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Tilt angle range: 0 - 140°, Swivel angle range: 0 - 180°, Distance to the wall (min): 5 cm, Distance to the wall (max): 37 cm. Product colour: Black

The Neomounts wall mount, model FPMA-W830BLACK is a tilt- and swivel wall mount for flat screens up to 27" (69 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Effortless pull the display out from the wall, position it in almost any direction, turn it around corners and then smoothly return it to the wall when finished.

Neomounts' tilt (20°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is easily depth adjustable from 4 to 36 centimetres.

Neomounts FPMA-W830BLACK has three pivot points and is suitable for screens up to 27" (69 cm). The weight capacity of this product is 12 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 75x75 and 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.

Create a clean design ambiance for your flat screen TV in the living room, bedroom or home cinema.

All installation material is included with the product.

Mounting

Maximum weight capacity: 12 kg
Minimum screen size: 25.4 cm (10")
Number of displays supported: 1
Maximum weight capacity (per display): 12 kg
Maximum screen size: 68.6 cm (27")
Minimum VESA mount: 75 x 75 mm
Maximum VESA mount: 100 x 100 mm
Panel mounting interface: 100 x 100,75 x 75 mm
Mounting type: Wall

Ergonomics

Feature: Tilt adjustment
Tilt angle range: 0 - 140°
Feature: Swivelling
Swivel angle: 180°
Swivel angle range: 0 - 180°
Feature: Rotating
Type: Full motion
Distance to the wall (max): 37 cm
Distance to the wall (min): 5 cm

Design

Product colour: Black
Housing material: Aluminium

Technical details

Country of origin: China
Package net weight: 960 g

Weight & dimensions

Weight: 880 g

Packaging data

Package width: 178 mm
Package depth: 45 mm
Package height: 233 mm
Package weight: 1 kg

Logistics data

Master (outer) case width: 375 mm
Master (outer) case length: 330 mm
Master (outer) case height: 250 mm
Master (outer) case gross weight: 12.9 kg
Master (outer) case net weight: 11.5 kg
Products per master (outer) case: 12 pc(s)
Harmonized System (HS) code: 7616991099
Products per pallet (EU): 360 pc(s)
