Neomounts DS75-450BL2 Screen Desk Mount, 2 screens, 17 - 32 inch, Topfix clamp & grommet
Neomounts DS75-450BL2 Screen Desk Mount, 2 screens, 17 - 32 inch, Topfix clamp & grommet
Guarantee
24 month
Delivery from Lithuania in
3 - 8
business days
The Neomounts DS75-450BL2 NEXT Core is a full motion desk mount for two flat screens up to 32" with a maximum weight capacity of 8 kg per screen. The versatile tilt (20°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the screens. Additionally, the mount has gas spring height adjustment (29,1-56 cm) and depth adjustment (14,3-55,3 cm), to create the perfect working position.
The DS75-450BL2 NEXT Core features the nifty 180° stop mechanism, that allows you to safely adjust the mount even when it's placed close to a wall or separation panel without making contact with the wall. The smart cable management system ensures orderly routing of the cables.
The DS75-450BL2 is suitable for screens that meet VESA hole pattern 75x75 or 100x100 mm. Unused hole patterns can be covered using one of Neomounts VESA adapter plates. The desk mount is equipped with an Quick-release VESA system and comes with both a topfix clamp and grommet for quick and easy installation.
The inner packaging of the NEXT Core is plastic free and made from cardboard and paper.
For wall installation, the AWL75-450WH wall adapter is optionally available.
| Summary: | Neomounts DS75-450BL2 Monitor arm 17-32" - gas spring - Topfix - 180°-stop. Mounting: Clamp/Grommet, Maximum weight capacity: 8 kg, Minimum screen size: 43.2 cm (17"), Maximum screen size: 81.3 cm (32"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: -90 - 90°, Tilt angle range: -10 - 10°. Product colour: Black |
| Vendor Homepage: | https://www.neomounts.com/default.asp?pageid=44&artdetail=DS75-450BL2 |
| Category Code: | MAS |
| CnCode: | 83021000 |
| Unit Box Height: | 0.325 |
| Unit Box Length: | 0.45 |
| Unit Box Width: | 0.155 |
| Desk thickness (max): | 45mm |
| Desk thickness (min): | 10mm |
| Maximum screen size: | 32" |
| Maximum VESA mount: | 100 x 100mm |
| Maximum weight capacity: | 8kg |
| Maximum weight capacity (per display): | 8kg |
| Minimum screen size: | 17" |
| Minimum VESA mount: | 75 x 75mm |
| Mounting: | Clamp/Grommet |
| Mounting type: | Desk |
| Number of displays supported: | 2 |
| Panel mounting interface: | 100 x 100/75 x 75mm |
| Adjustable depth: | Yes |
| Angle of rotation: | 360° |
| Cable management: | Yes |
| Depth adjustment range: | 143 - 553mm |
| Height adjustment: | Yes |
| Height adjustment range: | 291 - 560mm |
| Height adjustment type: | Gas spring |
| Pivot angle: | -180 - 180° |
| Rotating: | Yes |
| Swivel angle: | 20° |
| Swivel angle range: | -90 - 90° |
| Swivelling: | Yes |
| Tilt adjustment: | Yes |
| Tilt angle range: | -10 - 10° |
| Width adjustment: | 990mm |
| Housing material: | Steel |
| Product colour: | Black |
| Depth: | 115mm |
| Height: | 646mm |
| Weight: | 6400g |
| Width: | 761mm |
| Package depth: | 152mm |
| Package height: | 445mm |
| Package net weight: | 7900g |
| Package weight: | 7900g |
| Package width: | 320mm |
| Mounting kit: | Yes |
| Minimum weight: | 1kg |
| Warranty period: | 5year(s) |
| Width adjustment range: | 0 - 990mm |
| Country of origin: | China |
| Harmonized System (HS) code: | 7326909890 |
| Master (outer) case gross weight: | 15900g |
| Master (outer) case height: | 460mm |
| Master (outer) case length: | 325mm |
| Master (outer) case net weight: | 14300g |
| Master (outer) case width: | 335mm |
| Products per master (outer) case: | 2pc(s) |
| Products per pallet (EU): | 40pc(s) |
| Model: | DS75-450BL2 |
| Units per Shipping Box: | 1 |
| Unit Calculated Volume: | 0.02267m³ |
| Unit Calculated Weight: | 7.55kg |
