Lindy 36493 DisplayPort cable
Product reference: 29-4002888364935

Lindy 3m DisplayPort 1.2 Cable, Black Line, 3 m, DisplayPort, DisplayPort, Male, Male, 4096 x 2160 pixels

Lindy 36493 DisplayPort cable

Product reference: 29-4002888364935

Lindy 3m DisplayPort 1.2 Cable, Black Line, 3 m, DisplayPort, DisplayPort, Male, Male, 4096 x 2160 pixels

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
45,96 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
5 - 10
business days

Your message has been successfully sent!
Fill in the required fields*

Lindy 3m DisplayPort 1.2 Cable, Black Line. Cable length: 3 m, Connector 1: DisplayPort, Connector 2: DisplayPort. Compliance certificates: REACH, RoHS, UL, Certification: RoHS, REACH, UL. Cable diameter: 6 mm, Connector 1 dimensions (WxDxH): 21 x 38.9 x 13.6 mm, Connector 2 dimensions (WxDxH): 21 x 38.9 x 13.6 mm. Package width: 259 mm, Package depth: 236 mm, Package height: 15 mm. Quantity per pack: 1 pc(s)

Features

Connector 1 form factor: Straight
Connector 2 form factor: Straight
Connector contacts plating: Gold
DisplayPort version: 1.2
Maximum resolution: 4096 x 2160 pixels
Supported graphics resolutions: 4096 x 2160
Maximum refresh rate: 60 Hz
Cable length: 3 m
Connector 1: DisplayPort
Connector 2: DisplayPort
Connector 1 gender: Male
Connector 2 gender: Male
Product colour: Black
Cable material: Copper
Cable shielding: Copper
Jacket material: Polyvinyl chloride (PVC)
Connector housing material: Acrylonitrile butadiene styrene (ABS)
AWG wire size: 30
Data transfer rate: 21.6 Gbit/s
Contact material: Phosphor bronze
Connector material: Nickel
Feature: Plug and Play
Colour sampling: 4:4:4
Cable type: Round cable
Nominal attenuation: 300kHz-825MHz - <5dB, 825MHz-2.475GHz - <5dB, 2.475GHz-4.125GHz - <12dB, 4.125GHz-5.1GHz - <20dB

Operational conditions

Operating temperature (T-T): -20 - 80 °C
Storage temperature (T-T): -25 - 85 °C

Certificates

Compliance certificates: REACH, RoHS, UL
Certification: RoHS, REACH, UL

Weight & dimensions

Cable diameter: 6 mm
Connector 1 dimensions (WxDxH): 21 x 38.9 x 13.6 mm
Connector 2 dimensions (WxDxH): 21 x 38.9 x 13.6 mm
Bend radius (min): 4.8 cm

Packaging data

Package width: 259 mm
Package depth: 236 mm
Package height: 15 mm
Package type: Polybag

Packaging content

Quantity per pack: 1 pc(s)

Technical details

Housing material: Acrylonitrile butadiene styrene (ABS)

Logistics data

Harmonized System (HS) code: 84733080
Products per master (outer) case: 40 pc(s)

Other features

Connector(s): DP Male to DP Male
Depth: 42.6 mm
Height: 13 mm
Supported resolutions: 4 10bit
Width: 20.7 mm


Gamintojo kodas 36493
Weight 0.15 kg
