Lindy 36482 DisplayPort cable
Product reference: 29-4002888364829

Lindy 2m DisplayPort 1.4 Cable, Anthra Line, 2 m, DisplayPort, DisplayPort, Male, Male, 7680 x 4320 pixels

Lindy 36482 DisplayPort cable

Product reference: 29-4002888364829

Lindy 2m DisplayPort 1.4 Cable, Anthra Line, 2 m, DisplayPort, DisplayPort, Male, Male, 7680 x 4320 pixels

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
49,68 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
5 - 10
business days

Your message has been successfully sent!
Fill in the required fields*

Lindy 2m DisplayPort 1.4 Cable, Anthra Line. Cable length: 2 m, Connector 1: DisplayPort, Connector 2: DisplayPort. Compliance certificates: REACH, RoHS, UL, Certification: RoHS, REACH, UL. Cable diameter: 7 mm, Connector 1 dimensions (WxDxH): 21 x 38.9 x 13.6 mm, Bend radius (min): 5.84 cm. Package width: 194 mm, Package depth: 174 mm, Package height: 20 mm. Products per master (outer) case: 40 pc(s)

Features

Connector 1 form factor: Straight
Connector 2 form factor: Straight
Connector contacts plating: Gold
DisplayPort version: 1.4
Maximum resolution: 7680 x 4320 pixels
Supported graphics resolutions: 4096 x 2160, 7680 x 4320
Cable length: 2 m
Connector 1: DisplayPort
Connector 2: DisplayPort
Connector 1 gender: Male
Connector 2 gender: Male
Product colour: Black
Cable material: Tinned copper
Cable shielding: Copper
Jacket material: Polyvinyl chloride (PVC)
Connector housing material: Acrylonitrile butadiene styrene (ABS)
AWG wire size: 28
Data transfer rate: 32.4 Gbit/s
Contact material: Phosphor bronze
Connector material: Gold
Colour sampling: 4:2:2
Cable type: Round cable
Nominal attenuation: 100MHz-450MHz <5.1dB, 450MHz-8100MHz <33.28dB

Operational conditions

Operating temperature (T-T): -20 - 80 °C
Storage temperature (T-T): -25 - 85 °C

Certificates

Compliance certificates: REACH, RoHS, UL
Certification: RoHS, REACH, UL

Weight & dimensions

Cable diameter: 7 mm
Connector 1 dimensions (WxDxH): 21 x 38.9 x 13.6 mm
Bend radius (min): 5.84 cm

Packaging data

Package width: 194 mm
Package depth: 174 mm
Package height: 20 mm
Package type: Polybag

Technical details

Housing material: Acrylonitrile butadiene styrene (ABS)

Logistics data

Harmonized System (HS) code: 84733080
Products per master (outer) case: 40 pc(s)

Other features

Connector(s): DP Male to DP Male
Depth: 42.6 mm
Height: 13 mm
Supported resolutions: 2 10bit
Width: 20.7 mm


Gamintojo kodas 36482
Weight 0.146 kg
