Equip 650335 TV mount / stand

Equip 37"-80" Full Motion TV Wall Mount Bracket. Maximum weight capacity: 60 kg, Minimum screen size: 94 cm (37"), Maximum screen size: 2.03 m (80"), Minimum VESA mount: 200 x 200 mm, Maximum VESA mount: 600 x 400 mm. Tilt angle range: -15 - 5°, Distance to the wall (min): 5.8 cm, Distance to the wall (max): 40.2 cm. Product colour: Black
The equip® 650335 TV Wall Mount Bracket is a compact but sturdy product that ensures a reliable installation of your LCD/LED TV. Follow the graphic guide included in the package, you can install your TV on your own with ease. The wall bracket fits most of the wall materials- brick, concrete and wood, making the ideal choice for you to set up your screens.

Mounting

Maximum weight capacity: 60 kg
Minimum screen size: 94 cm (37")
Number of displays supported: 1
Maximum screen size: 2.03 m (80")
Minimum VESA mount: 200 x 200 mm
Maximum VESA mount: 600 x 400 mm
Panel mounting interface: 200 x 200,300 x 200,300 x 300,400 x 200,400 x 400,400 x 300,600 x 400
Mounting type: Wall

Ergonomics

Feature: Tilt adjustment
Tilt angle range: -15 - 5°
Pan range: -60 - 60°
Distance to the wall (max): 40.2 cm
Distance to the wall (min): 5.8 cm

Design

Product colour: Black
Housing material: Plastic, Stainless steel

Technical details

Country of origin: China

Packaging content

Feature: Manual
Feature: Mounting kit
Feature: Screw nuts included

Weight dimensions

Width: 710 mm
Depth (max): 43 cm
Height: 402 mm
Weight: 5.2 kg

Packaging data

Quantity per pack: 1 pair(s)
Package width: 436 mm
Package depth: 65 mm
Package height: 298 mm
Package weight: 5.66 kg
Package type: Box

Logistics data

Harmonized System (HS) code: 85299097
