Equip 650151 monitor mount / stand

Equip 13"-27" Articulating Monitor Desk Mount Bracket. Mounting: Clamp, Maximum weight capacity: 8 kg, Minimum screen size: 33 cm (13"), Maximum screen size: 68.6 cm (27"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Swivel angle range: -90 - 90°, Tilt angle range: -45 - 45°. Product colour: Black

The equip® Monitor Desk Mount Bracket is a compact but sturdy product that ensures a reliable installation of your LCD/LED monitor. Follow the graphic guide included in the package, you can install your monitor on your own with ease.

Mounting

Maximum weight capacity: 8 kg
Minimum screen size: 33 cm (13")
Number of displays supported: 1
Maximum screen size: 68.6 cm (27")
Mounting: Clamp
Feature: Suitable for TV
Mounting type: Desk
Minimum VESA mount: 75 x 75 mm
Maximum VESA mount: 100 x 100 mm
Panel mounting interface: 75 x 75,100 x 100 mm
Extension arm (max): 42.8 cm

Ergonomics

Tilt angle range: -45 - 45°
Swivel angle range: -90 - 90°
Angle of rotation: 180°
Feature: Cable management

Design

Housing material: Aluminium, Plastic, Steel
Product colour: Black

Weight & dimensions

Width: 500 mm
Depth: 70 mm
Height: 450 mm
Weight: 3.15 kg

Packaging data

Package width: 160 mm
Package depth: 105 mm
Package height: 485 mm
Package weight: 3.4 kg

Packaging content

Feature: Clamp included
Feature: Screws included
Feature: Grommet base plate included
Feature: User guide

Logistics data

Harmonized System (HS) code: 85299097
